32180 Group User’s Manual (Rev.1.0)
CAN MODULE
13.2 CAN Module Related Registers
CAN0 Slot Interrupt Request Enable Register (CAN0SLIEN)
<Address: H
’0080 1010>CAN1 Slot Interrupt Request Enable Register (CAN1SLIEN)
<Address: H
’0080 1410>b0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 b15
IRB0 IRB1 IRB2 IRB3 IRB4 IRB6 IRB7 IRB8 IRB9 IRB10 IRB11 IRB12 IRB13 IRB14 IRB15IRB5
0000000000000000
<After reset: H’0000>
b Bit Name Function R W
0 IRB0 (slot 0 interrupt request enable bit) 0: Mask (disable) interrupt request R W
1 IRB1 (slot 1 interrupt request enable bit) 1: Enable interrupt request
2 IRB2 (slot 2 interrupt request enable bit)
3 IRB3 (slot 3 interrupt request enable bit)
4 IRB4 (slot 4 interrupt request enable bit)
5 IRB5 (slot 5 interrupt request enable bit)
6 IRB6 (slot 6 interrupt request enable bit)
7 IRB7 (slot 7 interrupt request enable bit)
8 IRB8 (slot 8 interrupt request enable bit)
9 IRB9 (slot 9 interrupt request enable bit)
10 IRB10 (slot 10 interrupt request enable bit)
11 IRB11 (slot 11 interrupt request enable bit)
12 IRB12 (slot 12 interrupt request enable bit)
13 IRB13 (slot 13 interrupt request enable bit)
14 IRB14 (slot 14 interrupt request enable bit)
15 IRB15 (slot 15 interrupt request enable bit)
This register is used to enable or disable the interrupt requests that will be generated when data transmission or
reception in each corresponding slot is completed. Setting IRBn (n = 0–15) to "1" enables the interrupt request
to be generated when data transmission or reception in the corresponding slot is completed. The CAN Slot
Interrupt Request Status Register (CANnSLIST) helps to know which slot requested the interrupt.
