13-37

32180 Group User’s Manual (Rev.1.0)

13.2 CAN Module Related Registers

CAN MODULE

Figure 13.2.5 Block Diagram of the CAN0 Transmit/Receive & Error Interrupt Requests (3/5)

F/F

EOIEN

EOIS

F/F

EPIEN

EPIS

F/F

BEIEN

BEIS

b15

b14

b13

Data bus

CAN bus error occurs

Go to error passive state

Go to bus off state

To the preceding page

(Level)

19-source inputs

CAN0ERIST (H'0080 1014)

CAN0ERIEN (H'0080 1015)

To the remaining 16-source inputs in the next page
