3
3-9
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (2/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 009C 10-bit A-D0 Data Register 6 11-31
(AD0DT6)
H'0080 009E 10-bit A-D0 Data Register 7 11-31
(AD0DT7)
H'0080 00A0 10-bit A-D0 Data Register 8 11-31
(AD0DT8)
H'0080 00A2 10-bit A-D0 Data Register 9 11-31
(AD0DT9)
H'0080 00A4 10-bit A-D0 Data Register 10 11-31
(AD0DT10)
H'0080 00A6 10-bit A-D0 Data Register 11 11-31
(AD0DT11)
H'0080 00A8 10-bit A-D0 Data Register 12 11-31
(AD0DT12)
H'0080 00AA 10-bit A-D0 Data Register 13 11-31
(AD0DT13)
H'0080 00AC 10-bit A-D0 Data Register 14 11-31
(AD0DT14)
H'0080 00AE 10-bit A-D0 Data Register 15 11-31
(AD0DT15)
(Use inhibited area)
H'0080 00D0 (Use inhibited area) 8-bit A-D0 Data Register 0 11-32
(AD08DT0)
H'0080 00D2 (Use inhibited area) 8-bit A-D0 Data Register 1 11-32
(AD08DT1)
H'0080 00D4 (Use inhibited area) 8-bit A-D0 Data Register 2 11-32
(AD08DT2)
H'0080 00D6 (Use inhibited area) 8-bit A-D0 Data Register 3 11-32
(AD08DT3)
H'0080 00D8 (Use inhibited area) 8-bit A-D0 Data Register 4 11-32
(AD08DT4)
H'0080 00DA (Use inhibited area) 8-bit A-D0 Data Register 5 11-32
(AD08DT5)
H'0080 00DC (Use inhibited area) 8-bit A-D0 Data Register 6 11-32
(AD08DT6)
H'0080 00DE (Use inhibited area) 8-bit A-D0 Data Register 7 11-32
(AD08DT7)
H'0080 00E0 (Use inhibited area) 8-bit A-D0 Data Register 8 11-32
(AD08DT8)
H'0080 00E2 (Use inhibited area) 8-bit A-D0 Data Register 9 11-32
(AD08DT9)
H'0080 00E4 (Use inhibited area) 8-bit A-D0 Data Register 10 11-32
(AD08DT10)
H'0080 00E6 (Use inhibited area) 8-bit A-D0 Data Register 11 11-32
(AD08DT11)
H'0080 00E8 (Use inhibited area) 8-bit A-D0 Data Register 12 11-32
(AD08DT12)
H'0080 00EA (Use inhibited area) 8-bit A-D0 Data Register 13 11-32
(AD08DT13)
H'0080 00EC (Use inhibited area) 8-bit A-D0 Data Register 14 11-32
(AD08DT14)
H'0080 00EE (Use inhibited area) 8-bit A-D0 Data Register 15 11-32
(AD08DT15)
(Use inhibited area)
H'0080 0100 SIO23 Interrupt Request Status Register SIO03 Interrupt Request Enable Register 12-9
(SI23STAT) (SI03EN) 12-10
H'0080 0102 SIO03 Interrupt Request Source Select Register (Use inhibited area) 12-11
(SI03SEL)
(Use inhibited area)
H'0080 0110 SIO0 Transmit Control Register SIO0 Transmit/Receive Mode Register 12-14
(S0TCNT) (S0MOD) 12-15
H'0080 0112 SIO0 Transmit Buffer Register 12-18
(S0TXB)
H'0080 0114 SIO0 Receive Buffer Register 12-19
(S0RXB)
|
|
|
