13
13-60
32180 Group User’s Manual (Rev.1.0)
CAN MODULE
13.2 CAN Module Related Registers
CAN0 Message Slot 0 Extended ID1 (C0MSL0EID1)
<Address: H
’0080 1103>CAN0 Message Slot 1 Extended ID1 (C0MSL1EID1)
<Address: H
’0080 1113>CAN0 Message Slot 2 Extended ID1 (C0MSL2EID1)
<Address: H
’0080 1123>CAN0 Message Slot 3 Extended ID1 (C0MSL3EID1)
<Address: H
’0080 1133>CAN0 Message Slot 4 Extended ID1 (C0MSL4EID1)
<Address: H
’0080 1143>CAN0 Message Slot 5 Extended ID1 (C0MSL5EID1)
<Address: H
’0080 1153>CAN0 Message Slot 6 Extended ID1 (C0MSL6EID1)
<Address: H
’0080 1163>CAN0 Message Slot 7 Extended ID1 (C0MSL7EID1)
<Address: H
’0080 1173>CAN0 Message Slot 8 Extended ID1 (C0MSL8EID1)
<Address: H
’0080 1183>CAN0 Message Slot 9 Extended ID1 (C0MSL9EID1)
<Address: H
’0080 1193>CAN0 Message Slot 10 Extended ID1 (C0MSL10EID1)
<Address: H
’0080 11A3>CAN0 Message Slot 11 Extended ID1 (C0MSL11EID1)
<Address: H
’0080 11B3>CAN0 Message Slot 12 Extended ID1 (C0MSL12EID1)
<Address: H
’0080 11C3>CAN0 Message Slot 13 Extended ID1 (C0MSL13EID1)
<Address: H
’0080 11D3>CAN0 Message Slot 14 Extended ID1 (C0MSL14EID1)
<Address: H
’0080 11E3>CAN0 Message Slot 15 Extended ID1 (C0MSL15EID1)
<Address: H
’0080 11F3>CAN1 Message Slot 0 Extended ID1 (C1MSL0EID1)
<Address: H
’0080 1503>CAN1 Message Slot 1 Extended ID1 (C1MSL1EID1)
<Address: H
’0080 1513>CAN1 Message Slot 2 Extended ID1 (C1MSL2EID1)
<Address: H
’0080 1523>CAN1 Message Slot 3 Extended ID1 (C1MSL3EID1)
<Address: H
’0080 1533>CAN1 Message Slot 4 Extended ID1 (C1MSL4EID1)
<Address: H
’0080 1543>CAN1 Message Slot 5 Extended ID1 (C1MSL5EID1)
<Address: H
’0080 1553>CAN1 Message Slot 6 Extended ID1 (C1MSL6EID1)
<Address: H
’0080 1563>CAN1 Message Slot 7 Extended ID1 (C1MSL7EID1)
<Address: H
’0080 1573>CAN1 Message Slot 8 Extended ID1 (C1MSL8EID1)
<Address: H
’0080 1583>CAN1 Message Slot 9 Extended ID1 (C1MSL9EID1)
<Address: H
’0080 1593>CAN1 Message Slot 10 Extended ID1 (C1MSL10EID1)
<Address: H
’0080 15A3>CAN1 Message Slot 11 Extended ID1 (C1MSL11EID1)
<Address: H
’0080 15B3>CAN1 Message Slot 12 Extended ID1 (C1MSL12EID1)
<Address: H
’0080 15C3>CAN1 Message Slot 13 Extended ID1 (C1MSL13EID1)
<Address: H
’0080 15D3>CAN1 Message Slot 14 Extended ID1 (C1MSL14EID1)
<Address: H
’0080 15E3>CAN1 Message Slot 15 Extended ID1 (C1MSL15EID1)
<Address: H
’0080 15F3>9 1011121314b15b8
EID6EID5EID4 EID7 EID8 EID9 EID10 EID11
????????
<After reset: Undefined>
b Bit Name Function R W
8–15 EID4–EID11 Extended ID4–extended ID11 R W
(Extended ID4–extended ID11)
These registers are the memory space for transmit and receive frames.
Note: • If the message slot is set for the receive slot standard ID format, an undefined value is written to
the EID bits when storing received data.
To Next Page
