13-61
13
32180 Group User’s Manual (Rev.1.0)
13.2 CAN Module Related Registers
CAN MODULE
CAN0 Message Slot 0 Extended ID2 (C0MSL0EID2)
<Address: H
’0080 1104>CAN0 Message Slot 1 Extended ID2 (C0MSL1EID2)
<Address: H
’0080 1114>CAN0 Message Slot 2 Extended ID2 (C0MSL2EID2)
<Address: H
’0080 1124>CAN0 Message Slot 3 Extended ID2 (C0MSL3EID2)
<Address: H
’0080 1134>CAN0 Message Slot 4 Extended ID2 (C0MSL4EID2)
<Address: H
’0080 1144>CAN0 Message Slot 5 Extended ID2 (C0MSL5EID2)
<Address: H
’0080 1154>CAN0 Message Slot 6 Extended ID2 (C0MSL6EID2)
<Address: H
’0080 1164>CAN0 Message Slot 7 Extended ID2 (C0MSL7EID2)
<Address: H
’0080 1174>CAN0 Message Slot 8 Extended ID2 (C0MSL8EID2)
<Address: H
’0080 1184>CAN0 Message Slot 9 Extended ID2 (C0MSL9EID2)
<Address: H
’0080 1194>CAN0 Message Slot 10 Extended ID2 (C0MSL10EID2)
<Address: H
’0080 11A4>CAN0 Message Slot 11 Extended ID2 (C0MSL11EID2)
<Address: H
’0080 11B4>CAN0 Message Slot 12 Extended ID2 (C0MSL12EID2)
<Address: H
’0080 11C4>CAN0 Message Slot 13 Extended ID2 (C0MSL13EID2)
<Address: H
’0080 11D4>CAN0 Message Slot 14 Extended ID2 (C0MSL14EID2)
<Address: H
’0080 11E4>CAN0 Message Slot 15 Extended ID2 (C0MSL15EID2)
<Address: H
’0080 11F4>CAN1 Message Slot 0 Extended ID2 (C1MSL0EID2)
<Address: H
’0080 1504>CAN1 Message Slot 1 Extended ID2 (C1MSL1EID2)
<Address: H
’0080 1514>CAN1 Message Slot 2 Extended ID2 (C1MSL2EID2)
<Address: H
’0080 1524>CAN1 Message Slot 3 Extended ID2 (C1MSL3EID2)
<Address: H
’0080 1534>CAN1 Message Slot 4 Extended ID2 (C1MSL4EID2)
<Address: H
’0080 1544>CAN1 Message Slot 5 Extended ID2 (C1MSL5EID2)
<Address: H
’0080 1554>CAN1 Message Slot 6 Extended ID2 (C1MSL6EID2)
<Address: H
’0080 1564>CAN1 Message Slot 7 Extended ID2 (C1MSL7EID2)
<Address: H
’0080 1574>CAN1 Message Slot 8 Extended ID2 (C1MSL8EID2)
<Address: H
’0080 1584>CAN1 Message Slot 9 Extended ID2 (C1MSL9EID2)
<Address: H
’0080 1594>CAN1 Message Slot 10 Extended ID2 (C1MSL10EID2)
<Address: H
’0080 15A4>CAN1 Message Slot 11 Extended ID2 (C1MSL11EID2)
<Address: H
’0080 15B4>CAN1 Message Slot 12 Extended ID2 (C1MSL12EID2)
<Address: H
’0080 15C4>CAN1 Message Slot 13 Extended ID2 (C1MSL13EID2)
<Address: H
’0080 15D4>CAN1 Message Slot 14 Extended ID2 (C1MSL14EID2)
<Address: H
’0080 15E4>CAN1 Message Slot 15 Extended ID2 (C1MSL15EID2)
<Address: H
’0080 15F4>123456b7b0
EID15EID14EID13EID12 EID16 EID17
??????
<After reset: Undefined>
b Bit Name Function R W
0, 3 No function assigned. Fix to "0". 00
2–7 EID12–EID17 Extended ID12–extended ID17 R W
(Extended ID12–extended ID17)
These registers are the memory space for transmit and receive frames.
Note: • If the message slot is set for the receive slot standard ID format, an undefined value is written to
the EID bits when storing received data.
