3
3-12
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (5/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0260 TOP2 Counter 10-75
(TOP2CT)
H'0080 0262 TOP2 Reload Register 10-76
(TOP2RL)
H'0080 0264 (Use inhibited area)
H'0080 0266 TOP2 Correction Register 10-77
(TOP2CC)
(Use inhibited area)
H'0080 0270 TOP3 Counter 10-75
(TOP3CT)
H'0080 0272 TOP3 Reload Register 10-76
(TOP3RL)
H'0080 0274 (Use inhibited area)
H'0080 0276 TOP3 Correction Register 10-77
(TOP3CC)
(Use inhibited area)
H'0080 0280 TOP4 Counter 10-75
(TOP4CT)
H'0080 0282 TOP4 Reload Register 10-76
(TOP4RL)
H'0080 0284 (Use inhibited area)
H'0080 0286 TOP4 Correction Register 10-77
(TOP4CC)
(Use inhibited area)
H'0080 0290 TOP5 Counter 10-75
(TOP5CT)
H'0080 0292 TOP5 Reload Register 10-76
(TOP5RL)
H'0080 0294 (Use inhibited area)
H'0080 0296 TOP5 Correction Register 10-77
(TOP5CC)
H'0080 0298 (Use inhibited area)
H'0080 029A TOP0–5 Control Register 0 10-71
(TOP05CR0)
H'0080 029C (Use inhibited area) TOP0–5 Control Register 1 10-71
(TOP05CR1)
(Use inhibited area)
H'0080 02A0 TOP6 Counter 10-75
(TOP6CT)
H'0080 02A2 TOP6 Reload Register 10-76
(TOP6RL)
H'0080 02A4 (Use inhibited area)
H'0080 02A6 TOP6 Correction Register 10-77
(TOP6CC)
H'0080 02A8 (Use inhibited area)
H'0080 02AA TOP6, 7 Control Register 10-73
(TOP67CR)
(Use inhibited area)
H'0080 02B0 TOP7 Counter 10-75
(TOP7CT)
H'0080 02B2 TOP7 Reload Register 10-76
(TOP7RL)
H'0080 02B4 (Use inhibited area)
H'0080 02B6 TOP7 Correction Register 10-77
(TOP7CC)
(Use inhibited area)
|
|
|
|
|
|
To Next Page
