ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (6/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 02C0 TOP8 Counter 10-75
(TOP8CT)
H'0080 02C2 TOP8 Reload Register 10-76
(TOP8RL)
H'0080 02C4 (Use inhibited area)
H'0080 02C6 TOP8 Correction Register 10-77
(TOP8CC)
(Use inhibited area)
H'0080 02D0 TOP9 Counter 10-75
(TOP9CT)
H'0080 02D2 TOP9 Reload Register 10-76
(TOP9RL)
H'0080 02D4 (Use inhibited area)
H'0080 02D6 TOP9 Correction Register 10-77
(TOP9CC)
(Use inhibited area)
H'0080 02E0 TOP10 Counter 10-75
(TOP10CT)
H'0080 02E2 TOP10 Reload Register 10-76
(TOP10RL)
H'0080 02E4 (Use inhibited area)
H'0080 02E6 TOP10 Correction Register 10-77
(TOP10CC)
H'0080 02E8 (Use inhibited area)
H'0080 02EA TOP8–10 Control Register 10-74
(TOP810CR)
(Use inhibited area)
H'0080 02FA TOP External Enable Permit Register 10-78
(TOPEEN)
H'0080 02FC TOP Enable Protect Register 10-78
(TOPPRO)
H'0080 02FE TOP Count Enable Register 10-79
(TOPCEN)
H'0080 0300 TIO0 Counter 10-109
(TIO0CT)
H'0080 0302 (Use inhibited area)
H'0080 0304 TIO0 Reload 1 Register 10-111
(TIO0RL1)
H'0080 0306 TIO0 Reload 0/ Measure Register 10-110
(TIO0RL0)
(Use inhibited area)
H'0080 0310 TIO1 Counter 10-109
(TIO1CT)
H'0080 0312 (Use inhibited area)
H'0080 0314 TIO1 Reload 1 Register 10-111
(TIO1RL1)
H'0080 0316 TIO1 Reload 0/ Measure Register 10-110
(TIO1RL0)
H'0080 0318 (Use inhibited area)
H'0080 031A TIO0–3 Control Register 0 10-102
(TIO03CR0)
H'0080 031C (Use inhibited area) TIO0–3 Control Register 1 10-103
(TIO03CR1)
(Use inhibited area)
H'0080 0320 TIO2 Counter 10-109
(TIO2CT)
H'0080 0322 (Use inhibited area)
|
|
|
|
|
