ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (7/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0324 TIO2 Reload 1 Register 10-111
(TIO2RL1)
H'0080 0326 TIO2 Reload 0/ Measure Register 10-110
(TIO2RL0)
(Use inhibited area)
H'0080 0330 TIO3 Counter 10-109
(TIO3CT)
H'0080 0332 (Use inhibited area)
H'0080 0334 TIO3 Reload 1 Register 10-111
(TIO3RL1)
H'0080 0336 TIO3 Reload 0/ Measure Register 10-110
(TIO3RL0)
(Use inhibited area)
H'0080 0340 TIO4 Counter 10-109
(TIO4CT)
H'0080 0343 (Use inhibited area)
H'0080 0344 TIO4 Reload 1 Register 10-111
(TIO4RL1)
H'0080 0346 TIO4 Reload 0/ Measure Register 10-110
(TIO4RL0)
H'0080 0348 (Use inhibited area)
H'0080 034A TIO4 Control Register TIO5 Control Register 10-104
(TIO4CR) (TIO5CR) 10-106
(Use inhibited area)
H'0080 0350 TIO5 Counter 10-109
(TIO5CT)
H'0080 0352 (Use inhibited area)
H'0080 0354 TIO5 Reload 1 Register 10-111
(TIO5RL1)
H'0080 0356 TIO5 Reload 0/ Measure Register 10-110
(TIO5RL0)
(Use inhibited area)
H'0080 0360 TIO6 Counter 10-109
(TIO6CT)
H'0080 0362 (Use inhibited area)
H'0080 0364 TIO6 Reload 1 Register 10-111
(TIO6RL1)
H'0080 0366 TIO6 Reload 0/ Measure Register 10-110
(TIO6RL0)
H'0080 0368 (Use inhibited area)
H'0080 036A TIO6 Control Register TIO7 Control Register 10-107
(TIO6CR) (TIO7CR) 10-108
(Use inhibited area)
H'0080 0370 TIO7 Counter 10-109
(TIO7CT)
H'0080 0372 (Use inhibited area)
H'0080 0374 TIO7 Reload 1 Register 10-111
(TIO7RL1)
H'0080 0376 TIO7 Reload 0/ Measure Register 10-110
(TIO7RL0)
(Use inhibited area)
H'0080 0380 TIO8 Counter 10-109
(TIO8CT)
H'0080 0382 (Use inhibited area)
H'0080 0384 TIO8 Reload 1 Register 10-111
(TIO8RL1)
|
|
|
|
|
|
