3
3-15
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (8/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0386 TIO8 Reload 0/ Measure Register 10-110
(TIO8RL0)
H'0080 0388 (Use inhibited area)
H'0080 038A TIO8 Control Register TIO9 Control Register 10-108
(TIO8CR) (TIO9CR) 10-109
(Use inhibited area)
H'0080 0390 TIO9 Counter 10-109
(TIO9CT)
H'0080 0392 (Use inhibited area)
H'0080 0394 TIO9 Reload 1 Register 10-111
(TIO9RL1)
H'0080 0396 TIO9 Reload 0/ Measure Register 10-110
(TIO9RL0)
(Use inhibited area)
H'0080 03BC TIO Enable Protect Register 10-112
(TIOPRO)
H'0080 03BE TIO Count Enable Register 10-113
(TIOCEN)
H'0080 03C0 TMS0 Counter 10-130
(TMS0CT)
H'0080 03C2 TMS0 Measure 3 Register 10-130
(TMS0MR3)
H'0080 03C4 TMS0 Measure 2 Register 10-130
(TMS0MR2)
H'0080 03C6 TMS0 Measure 1 Register 10-130
(TMS0MR1)
H'0080 03C8 TMS0 Measure 0 Register 10-130
(TMS0MR0)
H'0080 03CA TMS0 Control Register TMS1 Control Register 10-129
(TMS0CR) (TMS1CR)
(Use inhibited area)
H'0080 03D0 TMS1 Counter 10-130
(TMS1CT)
H'0080 03D2 TMS1 Measure 3 Register 10-130
(TMS1MR3)
H'0080 03D4 TMS1 Measure 2 Register 10-130
(TMS1MR2)
H'0080 03D6 TMS1 Measure 1 Register 10-130
(TMS1MR1)
H'0080 03D8 TMS1 Measure 0 Register 10-130
(TMS1MR0)
(Use inhibited area)
H'0080 03E0 TML0 Counter (Upper) 10-135
(TML0CT)
H'0080 03E2 (Lower)
(Use inhibited area)
H'0080 03EA (Use inhibited area) TML0 Control Register 10-134
(TML0CR)
(Use inhibited area)
H'0080 03F0 TML0 Measure 3 Register (Upper) 10-135
(TML0MR3)
H'0080 03F2 (Lower)
H'0080 03F4 TML0 Measure 2 Register (Upper) 10-135
(TML0MR2)
H'0080 03F6 (Lower)
H'0080 03F8 TML0 Measure 1 Register (Upper) 10-135
(TML0MR1)
H'0080 03FA (Lower)
|
|
|
|
|
|
To Next Page
