16
16-3
WAIT CONTROLLER
32180 Group User’s Manual (Rev.1.0)
16.1 Outline of the Wait Controller
Table 16.1.2 Number of Wait States that Can Be Set by the Wait Controller
Extended External Area
Address Number of Wait States Inserted
CS0 area H’0010 0000 to H’001F FFFF Zero to 7 wait states set by software
(external extension mode) + any number of wait states entered from the WAIT# pin
H’0000 0000 to H’001F FFFF (However, software settings have priority.)
(processor mode)
CS1 area H’0020 0000 to H’003F FFFF Zero to 7 wait states set by software
(external extension and + any number of wait states entered from the WAIT# pin
processor modes) (However, software settings have priority.)
CS2 area H’0040 0000 to H’005F FFFF Zero to 7 wait states set by software
(external extension and + any number of wait states entered from the WAIT# pin
processor modes) (However, software settings have priority.)
CS3 area H’0060 0000 to H’007F FFFF Zero to 7 wait states set by software
(external extension and + any number of wait states entered from the WAIT# pin
processor modes) (However, software settings have priority.)
