3
3-19
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (12/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0780 PWM Output 0 Disable Control Register PWM Output 0 Disable Level Control Register 10-174
(PO0DISCR) (PO0LVCR) 10-177
H'0080 0782 PWM Output 1 Disable Control Register PWM Output 1 Disable Level Control Register 10-174
(PO1DISCR) (PO1LVCR) 10-177
H'0080 0784 PWM Output 2 Disable Control Register PWM Output 2 Disable Level Control Register 10-175
(PO2DISCR) (PO2LVCR) 10-177
H'0080 0786 Clock Control Register (Use inhibited area) 18-5
(CLKCR)
(Use inhibited area)
H'0080 078C TID0 Counter 10-144
(TID0CT)
H'0080 078E TID0 Reload Register 10-144
(TID0RL)
H'0080 0790 TOU0_0 Counter (Upper) 10-161
(TOU00CTW) (TOU00CTH)
H'0080 0792 (Lower) 10-163
(TOU00CT)
H'0080 0794 TOU0_0 Reload Register TOU0_0 Reload 1 Register 10-164
(TOU00RLW) (TOU00RL1) 10-167
H'0080 0796 TOU0_0 Reload 0 Register 10-166
(TOU00RL0)
H'0080 0798 TOU0_1 Counter (Upper) 10-161
(TOU01CTW) (TOU01CTH)
H'0080 079A (Lower) 10-163
(TOU01CT)
H'0080 079C TOU0_1 Reload Register TOU0_1 Reload 1 Register 10-164
(TOU01RLW) (TOU01RL1) 10-167
H'0080 079E TOU0_1 Reload 0 Register 10-166
(TOU01RL0)
H'0080 07A0 TOU0_2 Counter (Upper) 10-161
(TOU02CTW) (TOU02CTH)
H'0080 07A2 (Lower) 10-163
(TOU02CT)
H'0080 07A4 TOU0_2 Reload Register TOU0_2 Reload 1 Register 10-164
(TOU02RLW) (TOU02RL1) 10-167
H'0080 07A6 TOU0_2 Reload 0 Register 10-166
(TOU02RL0)
H'0080 07A8 TOU0_3 Counter (Upper) 10-161
(TOU03CTW) (TOU03CTH)
H'0080 07AA (Lower) 10-163
(TOU03CT)
H'0080 07AC TOU0_3 Reload Register TOU0_3 Reload 1 Register 10-164
(TOU03RLW) (TOU03RL1) 10-167
H'0080 07AE TOU0_3 Reload 0 Register 10-166
(TOU03RL0)
H'0080 07B0 TOU0_4 Counter (Upper) 10-161
(TOU04CTW) (TOU04CTH)
H'0080 07B2 (Lower) 10-163
(TOU04CT)
H'0080 07B4 TOU0_4 Reload Register TOU0_4 Reload 1 Register 10-164
(TOU04RLW) (TOU04RL1) 10-167
H'0080 07B6 TOU0_4 Reload 0 Register 10-166
(TOU04RL0)
H'0080 07B8 TOU0_5 Counter (Upper) 10-161
(TOU05CTW) (TOU05CTH)
H'0080 07BA (Lower) 10-163
(TOU05CT)
H'0080 07BC TOU0_5 Reload Register TOU0_5 Reload 1 Register 10-164
(TOU05RLW) (TOU05RL1) 10-167
H'0080 07BE TOU0_5 Reload 0 Register 10-166
(TOU05RL0)
H'0080 07C0 TOU0_6 Counter (Upper) 10-161
(TOU06CTW) (TOU06CTH)
H'0080 07C2 (Lower) 10-163
(TOU06CT)
|
