3
3-20
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (13/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 07C4 TOU0_6 Reload Register TOU0_6 Reload 1 Register 10-164
(TOU06RLW) (TOU06RL1) 10-167
H'0080 07C6 TOU0_6 Reload 0 Register 10-166
(TOU06RL0)
H'0080 07C8 TOU0_7 Counter (Upper) 10-161
(TOU07CTW) (TOU07CTH)
H'0080 07CA (Lower) 10-163
(TOU07CT)
H'0080 07CC TOU0_7 Reload Register TOU0_7 Reload 1 Register 10-164
(TOU07RLW) (TOU07RL1) 10-167
H'0080 07CE TOU0_7 Reload 0 Register 10-166
(TOU07RL0)
H'0080 07D0 Prescaler Register 3 TID0 Control & Prescaler 3 Enable Register 10-12
(PRS3) (TID0PRS3EN) 10-141
H'0080 07D2 TOU0 Interrupt Request Mask Register TOU0 Interrupt Request Status Register 10-58
(TOU0IMA) (TOU0IST)
H'0080 07D4 (Use inhibited area) F/F21–28 Protect Register 10-31
(FF2128P)
H'0080 07D6 (Use inhibited area) F/F21–28 Data Register 10-33
(FF2128D)
H'0080 07D8 TOU0 Control Register 1 10-158
(TOU0CR1)
H'0080 07DA TOU0 Control Register 0 10-158
(TOU0CR0)
H'0080 07DC (Use inhibited area) TOU0 Enable Protect Register 10-168
(TOU0PRO)
H'0080 07DE (Use inhibited area) TOU0 Count Enable Register 10-169
(TOU0CEN)
H'0080 07E0 PWMOFF0 Input Processing Control Register TIN24, 25 Input Processing Control Register 10-171
(PWMOFF0CR) (TIN2425CR) 10-25
H'0080 07E2 TIN24, 25 Interrupt Request Mask Register TIN24, 25 Interrupt Request Status Register 10-53
(TIN2425IMA) (TIN2425IST)
(Use inhibited area)
H'0080 0A00 SIO45 Interrupt Request Status Register SIO45 Interrupt Request Enable Register 12-9
(SI45STAT) (SI45EN) 12-10
H'0080 0A02 SIO45 Interrupt Source Select Register (Use inhibited area) 12-11
(SI45SEL)
(Use inhibited area)
H'0080 0A10 SIO4 Transmit Control Register SIO4 Transmit/Receive Mode Register 12-14
(S4TCNT) (S4MOD) 12-15
H'0080 0A12 SIO4 Transmit Buffer Register 12-18
(S4TXB)
H'0080 0A14 SIO4 Receive Buffer Register 12-19
(S4RXB)
H'0080 0A16 SIO4 Receive Control Register SIO4 Baud Rate Register 12-20
(S4RCNT) (S4BAUR) 12-23
(Use inhibited area)
H'0080 0A20 SIO5 Transmit Control Register SIO5 Transmit/Receive Mode Register 12-14
(S5TCNT) (S5MOD) 12-15
H'0080 0A22 SIO5 Transmit Buffer Register 12-18
(S5TXB)
H'0080 0A24 SIO5 Receive Buffer Register 12-19
(S5RXB)
H'0080 0A26 SIO5 Receive Control Register SIO5 Baud Rate Register 12-20
(S5RCNT) (S5BAUR) 12-23
(Use inhibited area)
H'0080 0A80 A-D1 Single Mode Register 0 A-D1 Single Mode Register 1 11-16
(AD1SIM0) (AD1SIM1) 11-18
H'0080 0A82 (Use inhibited area)
H'0080 0A84 A-D1 Scan Mode Register 0 A-D1 Scan Mode Register 1 11-20
(AD1SCM0) (AD1SCM1) 11-22
H'0080 0A86 A-D1 Disconnection Detection Assist Function Control Register A-D1 Conversion Speed Control Register 11-25
(AD1DDACR) (AD1CVSCR) 11-24
H'0080 0A88 A-D1 Successive Approximation Register 11-29
(AD1SAR)
|
|
|
|
To Next Page
