Renesas M32R/ECU Series User Manual

3
3-21
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (14/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0A8A A-D1 Disconnection Detection Assist Method Select Register 11-26
(AD1DDASEL)
H'0080 0A8C A-D1 Comparate Data Register 11-30
(AD1CMP)
H'0080 0A8E (Use inhibited area)
H'0080 0A90 10-bit A-D1 Data Register 0 11-31
(AD1DT0)
H'0080 0A92 10-bit A-D1 Data Register 1 11-31
(AD1DT1)
H'0080 0A94 10-bit A-D1 Data Register 2 11-31
(AD1DT2)
H'0080 0A96 10-bit A-D1 Data Register 3 11-31
(AD1DT3)
H'0080 0A98 10-bit A-D1 Data Register 4 11-31
(AD1DT4)
H'0080 0A9A 10-bit A-D1 Data Register 5 11-31
(AD1DT5)
H'0080 0A9C 10-bit A-D1 Data Register 6 11-31
(AD1DT6)
H'0080 0A9E 10-bit A-D1 Data Register 7 11-31
(AD1DT7)
H'0080 0AA0 10-bit A-D1 Data Register 8 11-31
(AD1DT8)
H'0080 0AA2 10-bit A-D1 Data Register 9 11-31
(AD1DT9)
H'0080 0AA4 10-bit A-D1 Data Register 10 11-31
(AD1DT10)
H'0080 0AA6 10-bit A-D1 Data Register 11 11-31
(AD1DT11)
H'0080 0AA8 10-bit A-D1 Data Register 12 11-31
(AD1DT12)
H'0080 0AAA 10-bit A-D1 Data Register 13 11-31
(AD1DT13)
H'0080 0AAC 10-bit A-D1 Data Register 14 11-31
(AD1DT14)
H'0080 0AAE 10-bit A-D1 Data Register 15 11-31
(AD1DT15)
(Use inhibited area)
H'0080 0AD0 (Use inhibited area) 8-bit A-D1 Data Register 0 11-32
(AD18DT0)
H'0080 0AD2 (Use inhibited area) 8-bit A-D1 Data Register 1 11-32
(AD18DT1)
H'0080 0AD4 (Use inhibited area) 8-bit A-D1 Data Register 2 11-32
(AD18DT2)
H'0080 0AD6 (Use inhibited area) 8-bit A-D1 Data Register 3 11-32
(AD18DT3)
H'0080 0AD8 (Use inhibited area) 8-bit A-D1 Data Register 4 11-32
(AD18DT4)
H'0080 0ADA (Use inhibited area) 8-bit A-D1 Data Register 5 11-32
(AD18DT5)
H'0080 0ADC (Use inhibited area) 8-bit A-D1 Data Register 6 11-32
(AD18DT6)
H'0080 0ADE (Use inhibited area) 8-bit A-D1 Data Register 7 11-32
(AD18DT7)
H'0080 0AE0 (Use inhibited area) 8-bit A-D1 Data Register 8 11-32
(AD18DT8)
H'0080 0AE2 (Use inhibited area) 8-bit A-D1 Data Register 9 11-32
(AD18DT9)
H'0080 0AE4 (Use inhibited area) 8-bit A-D1 Data Register 10 11-32
(AD18DT10)
H'0080 0AE6 (Use inhibited area) 8-bit A-D1 Data Register 11 11-32
(AD18DT11)
H'0080 0AE8 (Use inhibited area) 8-bit A-D1 Data Register 12 11-32
(AD18DT12)
H'0080 0AEA (Use inhibited area) 8-bit A-D1 Data Register 13 11-32
(AD18DT13)
H'0080 0AEC (Use inhibited area) 8-bit A-D1 Data Register 14 11-32
(AD18DT14)
|
