3
3-22
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (15/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0AEE (Use inhibited area) 8-bit A-D1 Data Register 15 11-32
(AD18DT15)
(Use inhibited area)
H'0080 0B8C TID1 Counter 10-144
(TID1CT)
H'0080 0B8E TID1 Reload Register 10-144
(TID1RL)
H'0080 0B90 TOU1_0 Counter (Upper) 10-161
(TOU10CTW) (TOU10CTH)
H'0080 0B92 (Lower) 10-163
(TOU10CT)
H'0080 0B94 TOU1_0 Reload Register TOU1_0 Reload 1 Register 10-164
(TOU10RLW) (TOU10RL1) 10-167
H'0080 0B96 TOU1_0 Reload 0 Register 10-166
(TOU10RL0)
H'0080 0B98 TOU1_1 Counter (Upper) 10-161
(TOU11CTW) (TOU11CTH)
H'0080 0B9A (Lower) 10-163
(TOU11CT)
H'0080 0B9C TOU1_1 Reload Register TOU1_1 Reload 1 Register 10-164
(TOU11RLW) (TOU11RL1) 10-167
H'0080 0B9E TOU1_1 Reload 0 Register 10-166
(TOU11RL0)
H'0080 0BA0 TOU1_2 Counter (Upper) 10-161
(TOU12CTW) (TOU12CTH)
H'0080 0BA2 (Lower) 10-163
(TOU12CT)
H'0080 0BA4 TOU1_2 Reload Register TOU1_2 Reload 1 Register 10-164
(TOU12RLW) (TOU12RL1) 10-167
H'0080 0BA6 TOU1_2 Reload 0 Register 10-166
(TOU12RL0)
H'0080 0BA8 TOU1_3 Counter (Upper) 10-161
(TOU13CTW) (TOU13CTH)
H'0080 0BAA (Lower) 10-163
(TOU13CT)
H'0080 0BAC TOU1_3 Reload Register TOU1_3 Reload 1 Register 10-164
(TOU13RLW) (TOU13RL1) 10-167
H'0080 0BAE TOU1_3 Reload 0 Register 10-166
(TOU13RL0)
H'0080 0BB0 TOU1_4 Counter (Upper) 10-161
(TOU14CTW) (TOU14CTH)
H'0080 0BB2 (Lower) 10-163
(TOU14CT)
H'0080 0BB4 TOU1_4 Reload Register TOU1_4 Reload 1 Register 10-164
(TOU14RLW) (TOU14RL1) 10-167
H'0080 0BB6 TOU1_4 Reload 0 Register 10-166
(TOU14RL0)
H'0080 0BB8 TOU1_5 Counter (Upper) 10-161
(TOU15CTW) (TOU15CTH)
H'0080 0BBA (Lower) 10-163
(TOU15CT)
H'0080 0BBC TOU1_5 Reload Register TOU1_5 Reload 1 Register 10-164
(TOU15RLW) (TOU15RL1) 10-167
H'0080 0BBE TOU1_5 Reload 0 Register 10-166
(TOU15RL0)
H'0080 0BC0 TOU1_6 Counter (Upper) 10-161
(TOU16CTW) (TOU16CTH)
H'0080 0BC2 (Lower) 10-163
(TOU16CT)
H'0080 0BC4 TOU1_6 Reload Register TOU1_6 Reload 1 Register 10-164
(TOU16RLW) (TOU16RL1) 10-167
H'0080 0BC6 TOU1_6 Reload 0 Register 10-166
(TOU16RL0)
H'0080 0BC8 TOU1_7 Counter (Upper) 10-161
(TOU17CTW) (TOU17CTH)
H'0080 0BCA (Lower) 10-163
(TOU17CT)
|
To Next Page
