ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (16/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0BCC TOU1_7 Reload Register TOU1_7 Reload 1 Register 10-164
(TOU17RLW) (TOU17RL1) 10-167
H'0080 0BCE TOU1_7 Reload 0 Register 10-166
(TOU17RL0)
H'0080 0BD0 Prescaler Register 4 TID1 Control & Prescaler 4 Enable Register 10-12
(PRS4) (TID1PRS4EN) 10-142
H'0080 0BD2 TOU1 Interrupt Request Mask Register TOU1 Interrupt Request Status Register 10-60
(TOU1IMA) (TOU1IST)
H'0080 0BD4 (Use inhibited area) F/F29–36 Protect Register 10-31
(FF2936P)
H'0080 0BD6 (Use inhibited area) F/F29–36 Data Register 10-33
(FF2936D)
H'0080 0BD8 TOU1 Control Register 1 10-159
(TOU1CR1)
H'0080 0BDA TOU1 Control Register 0 10-159
(TOU1CR0)
H'0080 0BDC (Use inhibited area) TOU1 Enable Protect Register 10-168
(TOU1PRO)
H'0080 0BDE (Use inhibited area) TOU1 Count Enable Register 10-169
(TOU1CEN)
H'0080 0BE0 PWMOFF1 Input Processing Control Register TIN26, 27 Input Processing Control Register 10-171
(PWMOFF1CR) (TIN2627CR) 10-25
H'0080 0BE2 TIN26, 27 Interrupt Request Mask Register TIN26, 27 Interrupt Request Status Register 10-54
(TIN2627IMA) (TIN2627IST)
(Use inhibited area)
H'0080 0C8C TID2 Counter 10-144
(TID2CT)
H'0080 0C8E TID2 Reload Register 10-144
(TID2RL)
H'0080 0C90 TOU2_0 Counter (Upper) 10-161
(TOU20CTW) (TOU20CTH)
H'0080 0C92 (Lower) 10-163
(TOU20CT)
H'0080 0C94 TOU2_0 Reload Register TOU2_0 Reload 1 Register 10-164
(TOU20RLW) (TOU20RL1) 10-167
H'0080 0C96 TOU2_0 Reload 0 Register 10-166
(TOU20RL0)
H'0080 0C98 TOU2_1 Counter (Upper) 10-161
(TOU21CTW) (TOU21CTH)
H'0080 0C9A (Lower) 10-163
(TOU21CT)
H'0080 0C9C TOU2_1 Reload Register TOU2_1 Reload 1 Register 10-164
(TOU21RLW) (TOU21RL1) 10-167
H'0080 0C9E TOU2_1 Reload 0 Register 10-166
(TOU21RL0)
H'0080 0CA0 TOU2_2 Counter (Upper) 10-161
(TOU22CTW) (TOU22CTH)
H'0080 0CA2 (Lower) 10-163
(TOU22CT)
H'0080 0CA4 TOU2_2 Reload Register TOU2_2 Reload 1 Register 10-164
(TOU22RLW) (TOU22RL1) 10-167
H'0080 0CA6 TOU2_2 Reload 0 Register 10-166
(TOU22RL0)
H'0080 0CA8 TOU2_3 Counter (Upper) 10-161
(TOU23CTW) (TOU23CTH)
H'0080 0CAA (Lower) 10-163
(TOU23CT)
H'0080 0CAC TOU2_3 Reload Register TOU2_3 Reload 1 Register 10-164
(TOU23RLW) (TOU23RL1) 10-167
H'0080 0CAE TOU2_3 Reload 0 Register 10-166
(TOU23RL0)
H'0080 0CB0 TOU2_4 Counter (Upper) 10-161
(TOU24CTW) (TOU24CTH)
H'0080 0CB2 (Lower) 10-163
(TOU24CT)
H'0080 0CB4 TOU2_4 Reload Register TOU2_4 Reload 1 Register 10-164
(TOU24RLW) (TOU24RL1) 10-167
H'0080 0CB6 TOU2_4 Reload 0 Register 10-166
(TOU24RL0)
|
