ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (17/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0CB8 TOU2_5 Counter (Upper) 10-161
(TOU25CTW) (TOU25CTH)
H'0080 0CBA (Lower) 10-163
(TOU25CT)
H'0080 0CBC TOU2_5 Reload Register TOU2_5 Reload 1 Register 10-164
(TOU25RLW) (TOU25RL1) 10-167
H'0080 0CBE TOU2_5 Reload 0 Register 10-166
(TOU25RL0)
H'0080 0CC0 TOU2_6 Counter (Upper) 10-161
(TOU26CTW) (TOU26CTH)
H'0080 0CC2 (Lower) 10-163
(TOU26CT)
H'0080 0CC4 TOU2_6 Reload Register TOU2_6 Reload 1 Register 10-164
(TOU26RLW) (TOU26RL1) 10-167
H'0080 0CC6 TOU2_6 Reload 0 Register 10-166
(TOU26RL0)
H'0080 0CC8 TOU2_7 Counter (Upper) 10-161
(TOU27CTW) (TOU27CTH)
H'0080 0CCA (Lower) 10-163
(TOU27CT)
H'0080 0CCC TOU2_7 Reload Register TOU2_7 Reload 1 Register 10-164
(TOU27RLW) (TOU27RL1) 10-167
H'0080 0CCE TOU2_7 Reload 0 Register 10-166
(TOU27RL0)
H'0080 0CD0 Prescaler Register 5 TID2 Control & Prescaler 5 Enable Register 10-12
(PRS5) (TID2PRS5EN) 10-143
H'0080 0CD2 TOU2 Interrupt Request Mask Register TOU2 Interrupt Request Status Register 10-61
(TOU2IMA) (TOU2IST)
H'0080 0CD4 (Use inhibited area) F/F37–44 Protect Register 10-31
(FF3744P)
H'0080 0CD6 (Use inhibited area) F/F37–44 Data Register 10-34
(FF3744D)
H'0080 0CD8 TOU2 Control Register 1 10-160
(TOU2CR1)
H'0080 0CDA TOU2 Control Register 0 10-160
(TOU2CR0)
H'0080 0CDC (Use inhibited area) TOU2 Enable Protect Register 10-168
(TOU2PRO)
H'0080 0CDE (Use inhibited area) TOU2 Count Enable Register 10-169
(TOU2CEN)
H'0080 0CE0 PWMOFF2 Input Processing Control Register TIN28, 29 Input Processing Control Register 10-172
(PWMOFF2CR) (TIN2829CR) 10-25
H'0080 0CE2 TIN28, 29 Interrupt Request Mask Register TIN28, 29 Interrupt Request Status Register 10-54
(TIN2829IMA) (TIN2829IST)
(Use inhibited area)
H'0080 0FE0 TML1 Counter (Upper) 10-135
(TML1CT)
H'0080 0FE2 (Lower)
(Use inhibited area)
H'0080 0FEA (Use inhibited area) TML1 Control Register 10-134
(TML1CR)
(Use inhibited area)
H'0080 0FF0 TML1 Measure 3 Register (Upper) 10-135
(TML1MR3)
H'0080 0FF2 (Lower)
H'0080 0FF4 TML1 Measure 2 Register (Upper) 10-135
(TML1MR2)
H'0080 0FF6 (Lower)
H'0080 0FF8 TML1 Measure 1 Register (Upper) 10-135
(TML1MR1)
H'0080 0FFA (Lower)
|
|
|
