21

21-28

ELECTRICAL CHARACTERISTICS

32180 Group User's Manual (Rev.1.0)

Figure 21.7.3 SBI Timing

Figure 21.7.5 TINi Timing

Figure 21.7.4 TOi Timing

SBI#

[13] tw(SBIL)

0.2VCCE

0.2VCCE

BCLK

TOi

[15] td(BCLK-TOi)

0.8VCCE

0.2VCCE

0.2VCC-BUS

TINi

0.8VCCE

0.2VCCE

0.8VCCE

0.2VCCE

[14]

tw(TINi)

21.7 A.C. Characteristics (when VCCE = 5 V)
