21-34

ELECTRICAL CHARACTERISTICS

32180 Group User's Manual (Rev.1.0)

Figure 21.7.11 Bus Arbitration Timing

BCLK

HACK#

[36] th(BCLKH-HREQL)

[37] td(BCLKL-HACKL)

[38] tv(BCLKL-HACKL)

HREQ#

0.16VCC-BUS

0.43VCC-BUS

0.16VCC-BUS

[35] tsu(HREQL-BCLKH)

0.16VCC-BUS

Figure 21.7.12 Input Transition Time of JTAG Pins

JTCK, JTDI

JTMS, JTRST

[58]

[59]

0.8VCCE

0.2VCCE

0.8VCCE

0.2VCCE

Note: • The rated values here are guaranteed for the case where the measured pin load capacitance CL = 80 pF.

21.7 A.C. Characteristics (when VCCE = 5 V)
