ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (22/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 11C2 CAN0 Message Slot 12 Extended ID 0 CAN0 Message Slot 12 Extended ID 1 13-59
(C0MSL12EID0) (C0MSL12EID1) 13-60
H'0080 11C4 CAN0 Message Slot 12 Extended ID 2 CAN0 Message Slot 12 Data Length Register 13-61
(C0MSL12EID2) (C0MSL12DLC) 13-62
H'0080 11C6 CAN0 Message Slot 12 Data 0 CAN0 Message Slot 12 Data 1 13-63
(C0MSL12DT0) (C0MSL12DT1) 13-64
H'0080 11C8 CAN0 Message Slot 12 Data 2 CAN0 Message Slot 12 Data 3 13-65
(C0MSL12DT2) (C0MSL12DT3) 13-66
H'0080 11CA CAN0 Message Slot 12 Data 4 CAN0 Message Slot 12 Data 5 13-67
(C0MSL12DT4) (C0MSL12DT5) 13-68
H'0080 11CC CAN0 Message Slot 12 Data 6 CAN0 Message Slot 12 Data 7 13-69
(C0MSL12DT6) (C0MSL12DT7) 13-70
H'0080 11CE CAN0 Message Slot 12 Timestamp 13-71
(C0MSL12TSP)
H'0080 11D0 CAN0 Message Slot 13 Standard ID 0 CAN0 Message Slot 13 Standard ID 1 13-57
(C0MSL13SID0) (C0MSL13SID1) 13-58
H'0080 11D2 CAN0 Message Slot 13 Extended ID 0 CAN0 Message Slot 13 Extended ID 1 13-59
(C0MSL13EID0) (C0MSL13EID1) 13-60
H'0080 11D4 CAN0 Message Slot 13 Extended ID 2 CAN0 Message Slot 13 Data Length Register 13-61
(C0MSL13EID2) (C0MSL13DLC) 13-62
H'0080 11D6 CAN0 Message Slot 13 Data 0 CAN0 Message Slot 13 Data 1 13-63
(C0MSL13DT0) (C0MSL13DT1) 13-64
H'0080 11D8 CAN0 Message Slot 13 Data 2 CAN0 Message Slot 13 Data 3 13-65
(C0MSL13DT2) (C0MSL13DT3) 13-66
H'0080 11DA CAN0 Message Slot 13 Data 4 CAN0 Message Slot 13 Data 5 13-67
(C0MSL13DT4) (C0MSL13DT5) 13-68
H'0080 11DC CAN0 Message Slot 13 Data 6 CAN0 Message Slot 13 Data 7 13-69
(C0MSL13DT6) (C0MSL13DT7) 13-70
H'0080 11DE CAN0 Message Slot 13 Timestamp 13-71
(C0MSL13TSP)
H'0080 11E0 CAN0 Message Slot 14 Standard ID 0 CAN0 Message Slot 14 Standard ID 1 13-57
(C0MSL14SID0) (C0MSL14SID1) 13-58
H'0080 11E2 CAN0 Message Slot 14 Extended ID 0 CAN0 Message Slot 14 Extended ID 1 13-59
(C0MSL14EID0) (C0MSL14EID1) 13-60
H'0080 11E4 CAN0 Message Slot 14 Extended ID 2 CAN0 Message Slot 14 Data Length Register 13-61
(C0MSL14EID2) (C0MSL14DLC) 13-62
H'0080 11E6 CAN0 Message Slot 14 Data 0 CAN0 Message Slot 14 Data 1 13-63
(C0MSL14DT0) (C0MSL14DT1) 13-64
H'0080 11E8 CAN0 Message Slot 14 Data 2 CAN0 Message Slot 14 Data 3 13-65
(C0MSL14DT2) (C0MSL14DT3) 13-66
H'0080 11EA CAN0 Message Slot 14 Data 4 CAN0 Message Slot 14 Data 5 13-67
(C0MSL14DT4) (C0MSL14DT5) 13-68
H'0080 11EC CAN0 Message Slot 14 Data 6 CAN0 Message Slot 14 Data 7 13-69
(C0MSL14DT6) (C0MSL14DT7) 13-70
H'0080 11EE CAN0 Message Slot 14 Timestamp 13-71
(C0MSL14TSP)
H'0080 11F0 CAN0 Message Slot 15 Standard ID 0 CAN0 Message Slot 15 Standard ID 1 13-57
(C0MSL15SID0) (C0MSL15SID1) 13-58
H'0080 11F2 CAN0 Message Slot 15 Extended ID 0 CAN0 Message Slot 15 Extended ID 1 13-59
(C0MSL15EID0) (C0MSL15EID1) 13-60
H'0080 11F4 CAN0 Message Slot 15 Extended ID 2 CAN0 Message Slot 15 Data Length Register 13-61
(C0MSL15EID2) (C0MSL15DLC) 13-62
H'0080 11F6 CAN0 Message Slot 15 Data 0 CAN0 Message Slot 15 Data 1 13-63
(C0MSL15DT0) (C0MSL15DT1) 13-64
H'0080 11F8 CAN0 Message Slot 15 Data 2 CAN0 Message Slot 15 Data 3 13-65
(C0MSL15DT2) (C0MSL15DT3) 13-66
H'0080 11FA CAN0 Message Slot 15 Data 4 CAN0 Message Slot 15 Data 5 13-67
(C0MSL15DT4) (C0MSL15DT5) 13-68
H'0080 11FC CAN0 Message Slot 15 Data 6 CAN0 Message Slot 15 Data 7 13-69
(C0MSL15DT6) (C0MSL15DT7) 13-70
H'0080 11FE CAN0 Message Slot 15 Timestamp 13-71
(C0MSL15TSP)
(Use inhibited area)
H'0080 1400 CAN1 Control Register 13-15
(CAN1CNT)
H'0080 1402 CAN1 Status Register 13-18
(CAN1STAT)
H'0080 1404 CAN1 Frame Format Select Register 13-21
(CAN1FFS)
|
