3
3-30
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (23/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 1406 CAN1 Configuration Register 13-22
(CAN1CONF)
H'0080 1408 CAN1 Timestamp Count Register 13-24
(CAN1TSTMP)
H'0080 140A CAN1 Receive Error Count Register CAN1 Transmit Error Count Register 13-25
(CAN1REC) (CAN1TEC)
H'0080 140C CAN1 Slot Interrupt Request Status Register 13-29
(CAN1SLIST)
H'0080 140E (Use inhibited area)
H'0080 1410 CAN1 Slot Interrupt Request Enable Register 13-30
(CAN1SLIEN)
H'0080 1412 (Use inhibited area)
H'0080 1414 CAN1 Error Interrupt Request Status Register CAN1 Error Interrupt Request Enable Register 13-31
(CAN1ERIST) (CAN1ERIEN) 13-32
H'0080 1416 CAN1 Baud Rate Prescaler CAN1 Cause of Error Register 13-26
(CAN1BRP) (CAN1EF) 13-45
H'0080 1418 CAN1 Mode Register (Use inhibited area) 13-46
(CAN1MOD)
(Use inhibited area)
H'0080 1428 CAN1 Global Mask Register Standard ID 0 CAN1 Global Mask Register Standard ID 1 13-48
(C1GMSKS0) (C1GMSKS1)
H'0080 142A CAN1 Global Mask Register Extended ID 0 CAN1 Global Mask Register Extended ID 1 13-49
(C1GMSKE0) (C1GMSKE1)
H'0080 142C CAN1 Global Mask Register Extended ID 2 (Use inhibited area) 13-50
(C1GMSKE2)
H'0080 142E (Use inhibited area)
H'0080 1430 CAN1 Local Mask Register A Standard ID 0 CAN1 Local Mask Register A Standard ID 1 13-48
(C1LMSKAS0) (C1LMSKAS1)
H'0080 1432 CAN1 Local Mask Register A Extended ID 0 CAN1 Local Mask Register A Extended ID 1 13-49
(C1LMSKAE0) (C1LMSKAE1)
H'0080 1434 CAN1 Local Mask Register A Extended ID 2 (Use inhibited area) 13-50
(C1LMSKAE2)
H'0080 1436 (Use inhibited area)
H'0080 1438 CAN1 Local Mask Register B Standard ID 0 CAN1 Local Mask Register B Standard ID 1 13-48
(C1LMSKBS0) (C1LMSKBS1)
H'0080 143A CAN1 Local Mask Register B Extended ID 0 CAN1 Local Mask Register B Extended ID 1 13-49
(C1LMSKBE0) (C1LMSKBE1)
H'0080 143C CAN1 Local Mask Register B Extended ID 2 (Use inhibited area) 13-50
(C1LMSKBE2)
H'0080 143E (Use inhibited area)
H'0080 1440 CAN1 Single-Shot Mode Control Register 13-52
(CAN1SSMODE)
H'0080 1442 (Use inhibited area)
H'0080 1444 CAN1 Single-Shot Interrupt Request Status Register 13-33
(CAN1SSIST)
H'0080 1446 (Use inhibited area)
H'0080 1448 CAN1 Single-Shot Interrupt Request Enable Register 13-34
(CAN1SSIEN)
(Use inhibited area)
H'0080 1450 CAN1 Message Slot 0 Control Register CAN1 Message Slot 1 Control Register 13-53
(C1MSL0CNT) (C1MSL1CNT)
H'0080 1452 CAN1 Message Slot 2 Control Register CAN1 Message Slot 3 Control Register 13-53
(C1MSL2CNT) (C1MSL3CNT)
H'0080 1454 CAN1 Message Slot 4 Control Register CAN1 Message Slot 5 Control Register 13-53
(C1MSL4CNT) (C1MSL5CNT)
H'0080 1456 CAN1 Message Slot 6 Control Register CAN1 Message Slot 7 Control Register 13-53
(C1MSL6CNT) (C1MSL7CNT)
H'0080 1458 CAN1 Message Slot 8 Control Register CAN1 Message Slot 9 Control Register 13-53
(C1MSL8CNT) (C1MSL9CNT)
H'0080 145A CAN1 Message Slot 10 Control Register CAN1 Message Slot 11 Control Register 13-53
(C1MSL10CNT) (C1MSL11CNT)
|
|
To Next Page
