Renesas M32R/ECU Series User Manual

3
3-31
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (24/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 145C CAN1 Message Slot 12 Control Register CAN1 Message Slot 13 Control Register 13-53
(C1MSL12CNT) (C1MSL13CNT)
H'0080 145E CAN1 Message Slot 14 Control Register CAN1 Message Slot 15 Control Register 13-53
(C1MSL14CNT) (C1MSL15CNT)
(Use inhibited area)
H'0080 1500 CAN1 Message Slot 0 Standard ID 0 CAN1 Message Slot 0 Standard ID 1 13-57
(C1MSL0SID0) (C1MSL0SID1) 13-58
H'0080 1502 CAN1 Message Slot 0 Extended ID 0 CAN1 Message Slot 0 Extended ID 1 13-59
(C1MSL0EID0) (C1MSL0EID1) 13-60
H'0080 1504 CAN1 Message Slot 0 Extended ID 2 CAN1 Message Slot 0 Data Length Register 13-61
(C1MSL0EID2) (C1MSL0DLC) 13-62
H'0080 1506 CAN1 Message Slot 0 Data 0 CAN1 Message Slot 0 Data 1 13-63
(C1MSL0DT0) (C1MSL0DT1) 13-64
H'0080 1508 CAN1 Message Slot 0 Data 2 CAN1 Message Slot 0 Data 3 13-65
(C1MSL0DT2) (C1MSL0DT3) 13-66
H'0080 150A CAN1 Message Slot 0 Data 4 CAN1 Message Slot 0 Data 5 13-67
(C1MSL0DT4) (C1MSL0DT5) 13-68
H'0080 150C CAN1 Message Slot 0 Data 6 CAN1 Message Slot 0 Data 7 13-69
(C1MSL0DT6) (C1MSL0DT7) 13-70
H'0080 150E CAN1 Message Slot 0 Timestamp 13-71
(C1MSL0TSP)
H'0080 1510 CAN1 Message Slot 1 Standard ID 0 CAN1 Message Slot 1 Standard ID 1 13-57
(C1MSL1SID0) (C1MSL1SID1) 13-58
H'0080 1512 CAN1 Message Slot 1 Extended ID 0 CAN1 Message Slot 1 Extended ID 1 13-59
(C1MSL1EID0) (C1MSL1EID1) 13-60
H'0080 1514 CAN1 Message Slot 1 Extended ID 2 CAN1 Message Slot 1 Data Length Register 13-61
(C1MSL1EID2) (C1MSL1DLC) 13-62
H'0080 1516 CAN1 Message Slot 1 Data 0 CAN1 Message Slot 1 Data 1 13-63
(C1MSL1DT0) (C1MSL1DT1) 13-64
H'0080 1518 CAN1 Message Slot 1 Data 2 CAN1 Message Slot 1 Data 3 13-65
(C1MSL1DT2) (C1MSL1DT3) 13-66
H'0080 151A CAN1 Message Slot 1 Data 4 CAN1 Message Slot 1 Data 5 13-67
(C1MSL1DT4) (C1MSL1DT5) 13-68
H'0080 151C CAN1 Message Slot 1 Data 6 CAN1 Message Slot 1 Data 7 13-69
(C1MSL1DT6) (C1MSL1DT7) 13-70
H'0080 151E CAN1 Message Slot 1 Timestamp 13-71
(C1MSL1TSP)
H'0080 1520 CAN1 Message Slot 2 Standard ID 0 CAN1 Message Slot 2 Standard ID 1 13-57
(C1MSL2SID0) (C1MSL2SID1) 13-58
H'0080 1522 CAN1 Message Slot 2 Extended ID 0 CAN1 Message Slot 2 Extended ID 1 13-59
(C1MSL2EID0) (C1MSL2EID1) 13-60
H'0080 1524 CAN1 Message Slot 2 Extended ID 2 CAN1 Message Slot 2 Data Length Register 13-61
(C1MSL2EID2) (C1MSL2DLC) 13-62
H'0080 1526 CAN1 Message Slot 2 Data 0 CAN1 Message Slot 2 Data 1 13-63
(C1MSL2DT0) (C1MSL2DT1) 13-64
H'0080 1528 CAN1 Message Slot 2 Data 2 CAN1 Message Slot 2 Data 3 13-65
(C1MSL2DT2) (C1MSL2DT3) 13-66
H'0080 152A CAN1 Message Slot 2 Data 4 CAN1 Message Slot 2 Data 5 13-67
(C1MSL2DT4) (C1MSL2DT5) 13-68
H'0080 152C CAN1 Message Slot 2 Data 6 CAN1 Message Slot 2 Data 7 13-69
(C1MSL2DT6) (C1MSL2DT7) 13-70
H'0080 152E CAN1 Message Slot 2 Timestamp 13-71
(C1MSL2TSP)
H'0080 1530 CAN1 Message Slot 3 Standard ID 0 CAN1 Message Slot 3 Standard ID 1 13-57
(C1MSL3SID0) (C1MSL3SID1) 13-58
H'0080 1532 CAN1 Message Slot 3 Extended ID 0 CAN1 Message Slot 3 Extended ID 1 13-59
(C1MSL3EID0) (C1MSL3EID1) 13-60
H'0080 1534 CAN1 Message Slot 3 Extended ID 2 CAN1 Message Slot 3 Data Length Register 13-61
(C1MSL3EID2) (C1MSL3DLC) 13-62
H'0080 1536 CAN1 Message Slot 3 Data 0 CAN1 Message Slot 3 Data 1 13-63
(C1MSL3DT0) (C1MSL3DT1) 13-64
H'0080 1538 CAN1 Message Slot 3 Data 2 CAN1 Message Slot 3 Data 3 13-65
(C1MSL3DT2) (C1MSL3DT3) 13-66
H'0080 153A CAN1 Message Slot 3 Data 4 CAN1 Message Slot 3 Data 5 13-67
(C1MSL3DT4) (C1MSL3DT5) 13-68
H'0080 153C CAN1 Message Slot 3 Data 6 CAN1 Message Slot 3 Data 7 13-69
(C1MSL3DT6) (C1MSL3DT7) 13-70
H'0080 153E CAN1 Message Slot 3 Timestamp 13-71
(C1MSL3TSP)
|
