3
3-32
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (25/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 1540 CAN1 Message Slot 4 Standard ID 0 CAN1 Message Slot 4 Standard ID 1 13-57
(C1MSL4SID0) (C1MSL4SID1) 13-58
H'0080 1542 CAN1 Message Slot 4 Extended ID 0 CAN1 Message Slot 4 Extended ID 1 13-59
(C1MSL4EID0) (C1MSL4EID1) 13-60
H'0080 1544 CAN1 Message Slot 4 Extended ID 2 CAN1 Message Slot 4 Data Length Register 13-61
(C1MSL4EID2) (C1MSL4DLC) 13-62
H'0080 1546 CAN1 Message Slot 4 Data 0 CAN1 Message Slot 4 Data 1 13-63
(C1MSL4DT0) (C1MSL4DT1) 13-64
H'0080 1548 CAN1 Message Slot 4 Data 2 CAN1 Message Slot 4 Data 3 13-65
(C1MSL4DT2) (C1MSL4DT3) 13-66
H'0080 154A CAN1 Message Slot 4 Data 4 CAN1 Message Slot 4 Data 5 13-67
(C1MSL4DT4) (C1MSL4DT5) 13-68
H'0080 154C CAN1 Message Slot 4 Data 6 CAN1 Message Slot 4 Data 7 13-69
(C1MSL4DT6) (C1MSL4DT7) 13-70
H'0080 154E CAN1 Message Slot 4 Timestamp 13-71
(C1MSL4TSP)
H'0080 1550 CAN1 Message Slot 5 Standard ID 0 CAN1 Message Slot 5 Standard ID 1 13-57
(C1MSL5SID0) (C1MSL5SID1) 13-58
H'0080 1552 CAN1 Message Slot 5 Extended ID 0 CAN1 Message Slot 5 Extended ID 1 13-59
(C1MSL5EID0) (C1MSL5EID1) 13-60
H'0080 1554 CAN1 Message Slot 5 Extended ID 2 CAN1 Message Slot 5 Data Length Register 13-61
(C1MSL5EID2) (C1MSL5DLC) 13-62
H'0080 1556 CAN1 Message Slot 5 Data 0 CAN1 Message Slot 5 Data 1 13-63
(C1MSL5DT0) (C1MSL5DT1) 13-64
H'0080 1558 CAN1 Message Slot 5 Data 2 CAN1 Message Slot 5 Data 3 13-65
(C1MSL5DT2) (C1MSL5DT3) 13-66
H'0080 155A CAN1 Message Slot 5 Data 4 CAN1 Message Slot 5 Data 5 13-67
(C1MSL5DT4) (C1MSL5DT5) 13-68
H'0080 155C CAN1 Message Slot 5 Data 6 CAN1 Message Slot 5 Data 7 13-69
(C1MSL5DT6) (C1MSL5DT7) 13-70
H'0080 155E CAN1 Message Slot 5 Timestamp 13-71
(C1MSL5TSP)
H'0080 1560 CAN1 Message Slot 6 Standard ID 0 CAN1 Message Slot 6 Standard ID 1 13-57
(C1MSL6SID0) (C1MSL6SID1) 13-58
H'0080 1562 CAN1 Message Slot 6 Extended ID 0 CAN1 Message Slot 6 Extended ID 1 13-59
(C1MSL6EID0) (C1MSL6EID1) 13-60
H'0080 1564 CAN1 Message Slot 6 Extended ID 2 CAN1 Message Slot 6 Data Length Register 13-61
(C1MSL6EID2) (C1MSL6DLC) 13-62
H'0080 1566 CAN1 Message Slot 6 Data 0 CAN1 Message Slot 6 Data 1 13-63
(C1MSL6DT0) (C1MSL6DT1) 13-64
H'0080 1568 CAN1 Message Slot 6 Data 2 CAN1 Message Slot 6 Data 3 13-65
(C1MSL6DT2) (C1MSL6DT3) 13-66
H'0080 156A CAN1 Message Slot 6 Data 4 CAN1 Message Slot 6 Data 5 13-67
(C1MSL6DT4) (C1MSL6DT5) 13-68
H'0080 156C CAN1 Message Slot 6 Data 6 CAN1 Message Slot 6 Data 7 13-69
(C1MSL6DT6) (C1MSL6DT7) 13-70
H'0080 156E CAN1 Message Slot 6 Timestamp 13-71
(C1MSL6TSP)
H'0080 1570 CAN1 Message Slot 7 Standard ID 0 CAN1 Message Slot 7 Standard ID 1 13-57
(C1MSL7SID0) (C1MSL7SID1) 13-58
H'0080 1572 CAN1 Message Slot 7 Extended ID 0 CAN1 Message Slot 7 Extended ID 1 13-59
(C1MSL7EID0) (C1MSL7EID1) 13-60
H'0080 1574 CAN1 Message Slot 7 Extended ID 2 CAN1 Message Slot 7 Data Length Register 13-61
(C1MSL7EID2) (C1MSL7DLC) 13-62
H'0080 1576 CAN1 Message Slot 7 Data 0 CAN1 Message Slot 7 Data 1 13-63
(C1MSL7DT0) (C1MSL7DT1) 13-64
H'0080 1578 CAN1 Message Slot 7 Data 2 CAN1 Message Slot 7 Data 3 13-65
(C1MSL7DT2) (C1MSL7DT3) 13-66
H'0080 157A CAN1 Message Slot 7 Data 4 CAN1 Message Slot 7 Data 5 13-67
(C1MSL7DT4) (C1MSL7DT5) 13-68
H'0080 157C CAN1 Message Slot 7 Data 6 CAN1 Message Slot 7 Data 7 13-69
(C1MSL7DT6) (C1MSL7DT7) 13-70
H'0080 157E CAN1 Message Slot 7 Timestamp 13-71
(C1MSL7TSP)
H'0080 1580 CAN1 Message Slot 8 Standard ID 0 CAN1 Message Slot 8 Standard ID 1 13-57
(C1MSL8SID0) (C1MSL8SID1) 13-58
H'0080 1582 CAN1 Message Slot 8 Extended ID 0 CAN1 Message Slot 8 Extended ID 1 13-59
(C1MSL8EID0) (C1MSL8EID1) 13-60
H'0080 1584 CAN1 Message Slot 8 Extended ID 2 CAN1 Message Slot 8 Data Length Register 13-61
(C1MSL8EID2) (C1MSL8DLC) 13-62
