ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (26/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 1586 CAN1 Message Slot 8 Data 0 CAN1 Message Slot 8 Data 1 13-63
(C1MSL8DT0) (C1MSL8DT1) 13-64
H'0080 1588 CAN1 Message Slot 8 Data 2 CAN1 Message Slot 8 Data 3 13-65
(C1MSL8DT2) (C1MSL8DT3) 13-66
H'0080 158A CAN1 Message Slot 8 Data 4 CAN1 Message Slot 8 Data 5 13-67
(C1MSL8DT4) (C1MSL8DT5) 13-68
H'0080 158C CAN1 Message Slot 8 Data 6 CAN1 Message Slot 8 Data 7 13-69
(C1MSL8DT6) (C1MSL8DT7) 13-70
H'0080 158E CAN1 Message Slot 8 Timestamp 13-71
(C1MSL8TSP)
H'0080 1590 CAN1 Message Slot 9 Standard ID 0 CAN1 Message Slot 9 Standard ID 1 13-57
(C1MSL9SID0) (C1MSL9SID1) 13-58
H'0080 1592 CAN1 Message Slot 9 Extended ID 0 CAN1 Message Slot 9 Extended ID 1 13-59
(C1MSL9EID0) (C1MSL9EID1) 13-60
H'0080 1594 CAN1 Message Slot 9 Extended ID 2 CAN1 Message Slot 9 Data Length Register 13-61
(C1MSL9EID2) (C1MSL9DLC) 13-62
H'0080 1596 CAN1 Message Slot 9 Data 0 CAN1 Message Slot 9 Data 1 13-63
(C1MSL9DT0) (C1MSL9DT1) 13-64
H'0080 1598 CAN1 Message Slot 9 Data 2 CAN1 Message Slot 9 Data 3 13-65
(C1MSL9DT2) (C1MSL9DT3) 13-66
H'0080 159A CAN1 Message Slot 9 Data 4 CAN1 Message Slot 9 Data 5 13-67
(C1MSL9DT4) (C1MSL9DT5) 13-68
H'0080 159C CAN1 Message Slot 9 Data 6 CAN1 Message Slot 9 Data 7 13-69
(C1MSL9DT6) (C1MSL9DT7) 13-70
H'0080 159E CAN1 Message Slot 9 Timestamp 13-71
(C1MSL9TSP)
H'0080 15A0 CAN1 Message Slot 10 Standard ID 0 CAN1 Message Slot 10 Standard ID 1 13-57
(C1MSL10SID0) (C1MSL10SID1) 13-58
H'0080 15A2 CAN1 Message Slot 10 Extended ID 0 CAN1 Message Slot 10 Extended ID 1 13-59
(C1MSL10EID0) (C1MSL10EID1) 13-60
H'0080 15A4 CAN1 Message Slot 10 Extended ID 2 CAN1 Message Slot 10 Data Length Register 13-61
(C1MSL10EID2) (C1MSL10DLC) 13-62
H'0080 15A6 CAN1 Message Slot 10 Data 0 CAN1 Message Slot 10 Data 1 13-63
(C1MSL10DT0) (C1MSL10DT1) 13-64
H'0080 15A8 CAN1 Message Slot 10 Data 2 CAN1 Message Slot 10 Data 3 13-65
(C1MSL10DT2) (C1MSL10DT3) 13-66
H'0080 15AA CAN1 Message Slot 10 Data 4 CAN1 Message Slot 10 Data 5 13-67
(C1MSL10DT4) (C1MSL10DT5) 13-68
H'0080 15AC CAN1 Message Slot 10 Data 6 CAN1 Message Slot 10 Data 7 13-69
(C1MSL10DT6) (C1MSL10DT7) 13-70
H'0080 15AE CAN1 Message Slot 10 Timestamp 13-71
(C1MSL10TSP)
H'0080 15B0 CAN1 Message Slot 11 Standard ID 0 CAN1 Message Slot 11 Standard ID 1 13-57
(C1MSL11SID0) (C1MSL11SID1) 13-58
H'0080 15B2 CAN1 Message Slot 11 Extended ID 0 CAN1 Message Slot 11 Extended ID 1 13-59
(C1MSL11EID0) (C1MSL11EID1) 13-60
H'0080 15B4 CAN1 Message Slot 11 Extended ID 2 CAN1 Message Slot 11 Data Length Register 13-61
(C1MSL11EID2) (C1MSL11DLC) 13-62
H'0080 15B6 CAN1 Message Slot 11 Data 0 CAN1 Message Slot 11 Data 1 13-63
(C1MSL11DT0) (C1MSL11DT1) 13-64
H'0080 15B8 CAN1 Message Slot 11 Data 2 CAN1 Message Slot 11 Data 3 13-65
(C1MSL11DT2) (C1MSL11DT3) 13-66
H'0080 15BA CAN1 Message Slot 11 Data 4 CAN1 Message Slot 11 Data 5 13-67
(C1MSL11DT4) (C1MSL11DT5) 13-68
H'0080 15BC CAN1 Message Slot 11 Data 6 CAN1 Message Slot 11 Data 7 13-69
(C1MSL11DT6) (C1MSL11DT7) 13-70
H'0080 15BE CAN1 Message Slot 11 Timestamp 13-71
(C1MSL11TSP)
H'0080 15C0 CAN1 Message Slot 12 Standard ID 0 CAN1 Message Slot 12 Standard ID 1 13-57
(C1MSL12SID0) (C1MSL12SID1) 13-58
H'0080 15C2 CAN1 Message Slot 12 Extended ID 0 CAN1 Message Slot 12 Extended ID 1 13-59
(C1MSL12EID0) (C1MSL12EID1) 13-60
H'0080 15C4 CAN1 Message Slot 12 Extended ID 2 CAN1 Message Slot 12 Data Length Register 13-61
(C1MSL12EID2) (C1MSL12DLC) 13-62
H'0080 15C6 CAN1 Message Slot 12 Data 0 CAN1 Message Slot 12 Data 1 13-63
(C1MSL12DT0) (C1MSL12DT1) 13-64
H'0080 15C8 CAN1 Message Slot 12 Data 2 CAN1 Message Slot 12 Data 3 13-65
(C1MSL12DT2) (C1MSL12DT3) 13-66
H'0080 15CA CAN1 Message Slot 12 Data 4 CAN1 Message Slot 12 Data 5 13-67
(C1MSL12DT4) (C1MSL12DT5) 13-68
