Renesas M32R/ECU Series User Manual

3
3-34
ADDRESS SPACE
3.4 Internal RAM and SFR Areas
32180 Group User’s Manual (Rev.1.0)
SFR Area Register Map (27/27)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 15CC CAN1 Message Slot 12 Data 6 CAN1 Message Slot 12 Data 7 13-69
(C1MSL12DT6) (C1MSL12DT7) 13-70
H'0080 15CE CAN1 Message Slot 12 Timestamp 13-71
(C1MSL12TSP)
H'0080 15D0 CAN1 Message Slot 13 Standard ID 0 CAN1 Message Slot 13 Standard ID 1 13-57
(C1MSL13SID0) (C1MSL13SID1) 13-58
H'0080 15D2 CAN1 Message Slot 13 Extended ID 0 CAN1 Message Slot 13 Extended ID 1 13-59
(C1MSL13EID0) (C1MSL13EID1) 13-60
H'0080 15D4 CAN1 Message Slot 13 Extended ID 2 CAN1 Message Slot 13 Data Length Register 13-61
(C1MSL13EID2) (C1MSL13DLC) 13-62
H'0080 15D6 CAN1 Message Slot 13 Data 0 CAN1 Message Slot 13 Data 1 13-63
(C1MSL13DT0) (C1MSL13DT1) 13-64
H'0080 15D8 CAN1 Message Slot 13 Data 2 CAN1 Message Slot 13 Data 3 13-65
(C1MSL13DT2) (C1MSL13DT3) 13-66
H'0080 15DA CAN1 Message Slot 13 Data 4 CAN1 Message Slot 13 Data 5 13-67
(C1MSL13DT4) (C1MSL13DT5) 13-68
H'0080 15DC CAN1 Message Slot 13 Data 6 CAN1 Message Slot 13 Data 7 13-69
(C1MSL13DT6) (C1MSL13DT7) 13-70
H'0080 15DE CAN1 Message Slot 13 Timestamp 13-71
(C1MSL13TSP)
H'0080 15E0 CAN1 Message Slot 14 Standard ID 0 CAN1 Message Slot 14 Standard ID 1 13-57
(C1MSL14SID0) (C1MSL14SID1) 13-58
H'0080 15E2 CAN1 Message Slot 14 Extended ID 0 CAN1 Message Slot 14 Extended ID 1 13-59
(C1MSL14EID0) (C1MSL14EID1) 13-60
H'0080 15E4 CAN1 Message Slot 14 Extended ID 2 CAN1 Message Slot 14 Data Length Register 13-61
(C1MSL14EID2) (C1MSL14DLC) 13-62
H'0080 15E6 CAN1 Message Slot 14 Data 0 CAN1 Message Slot 14 Data 1 13-63
(C1MSL14DT0) (C1MSL14DT1) 13-64
H'0080 15E8 CAN1 Message Slot 14 Data 2 CAN1 Message Slot 14 Data 3 13-65
(C1MSL14DT2) (C1MSL14DT3) 13-66
H'0080 15EA CAN1 Message Slot 14 Data 4 CAN1 Message Slot 14 Data 5 13-67
(C1MSL14DT4) (C1MSL14DT5) 13-68
H'0080 15EC CAN1 Message Slot 14 Data 6 CAN1 Message Slot 14 Data 7 13-69
(C1MSL14DT6) (C1MSL14DT7) 13-70
H'0080 15EE CAN1 Message Slot 14 Timestamp 13-71
(C1MSL14TSP)
H'0080 15F0 CAN1 Message Slot 15 Standard ID 0 CAN1 Message Slot 15 Standard ID 1 13-57
(C1MSL15SID0) (C1MSL15SID1) 13-58
H'0080 15F2 CAN1 Message Slot 15 Extended ID 0 CAN1 Message Slot 15 Extended ID 1 13-59
(C1MSL15EID0) (C1MSL15EID1) 13-60
H'0080 15F4 CAN1 Message Slot 15 Extended ID 2 CAN1 Message Slot 15 Data Length Register 13-61
(C1MSL15EID2) (C1MSL15DLC) 13-62
H'0080 15F6 CAN1 Message Slot 15 Data 0 CAN1 Message Slot 15 Data 1 13-63
(C1MSL15DT0) (C1MSL15DT1) 13-64
H'0080 15F8 CAN1 Message Slot 15 Data 2 CAN1 Message Slot 15 Data 3 13-65
(C1MSL15DT2) (C1MSL15DT3) 13-66
H'0080 15FA CAN1 Message Slot 15 Data 4 CAN1 Message Slot 15 Data 5 13-67
(C1MSL15DT4) (C1MSL15DT5) 13-68
H'0080 15FC CAN1 Message Slot 15 Data 6 CAN1 Message Slot 15 Data 7 13-69
(C1MSL15DT6) (C1MSL15DT7) 13-70
H'0080 15FE CAN1 Message Slot 15 Timestamp 13-71
(C1MSL15TSP)
