RuggedCom RUGGEDBACKBONE RX5000 User Manual

25. Spanning Tree
ROX™ v2.2 User Guide 247 RuggedBackbone™ RX5000
25.4.2. Port RSTP Parameters
Figure 25.10. Interface/switch/{line module}/spanning-tree submenu
This submenu is accessible from the main menu under interface/switch/{line module}/spanning-tree.
Figure 25.11. Port RSTP Parameter form
The Port RSTP Parameter form appears on the same screen as the interface/switch/{line module}/
spanning-tree submenu.
Enabled
Synopsis: boolean
Default: true
When the box is checked, the Spanning Tree Protocol is enabled on the interface. Enabling STP
activates the STP or RSTP protocol for this interface per the configuration in the STP Configuration
menu.
Admin Edge
Synopsis: string - one of the following keywords { auto, forceFalse, forceTrue }
Default: auto

RuggedCom RUGGEDBACKBONE RX5000 Specifications

General

Brand	RuggedCom
Model	RUGGEDBACKBONE RX5000
Category	Switch
Language	English
