4. Basic Network Configuration
ROX™ v2.2 User Guide 70 RuggedBackbone™ RX5000
Figure 4.2. Configuring an IP Address
Procedure 4.1. Configuring an IP Address
1. Enter Edit Private mode.
2. Navigate to ip/interface/ipv4.
3. To delete an existing IP address, click the delete icon.
4. Click Add address. The Key settings form appears.
5. In the IPaddress field, type the new IP address.
6. Click Commit.
7. Click Exit Transaction.
To create additional interfaces, see Section 5.3, “Adding Interfaces to Switched Ports”.
4.1.2. Simple Network Setup with the Default IPv4 Addresses
This section describes how to set up a simple network using the factory default IPv4 address.
Figure 4.3. Basic Network Setup Using the Default IPv4 Addresses
