RuggedCom RUGGEDBACKBONE RX5000 - Nexthop to Other System Form

30. Tunnelling
ROX™ v2.2 User Guide 313 RuggedBackbone™ RX5000
Figure 30.17. Nexthop To Other System form
Type
Synopsis: string - one of the following keywords { address, default-route, default }
Default: default
Type.
IP Address
Synopsis: IPv4 address in dotted-decimal notation
IP address.
Figure 30.18. System Identifier form
type
Synopsis: string - one of the following keywords { hostname, address, from-certificate, none,
default }
Default: default
Type.
Hostname or IP Address
Synopsis: A string conforming to: "[^ ]+"
Hostname or IP address.
Figure 30.19. Private Subnet Behind System form
If data is configured, the path to the Private Subnet Behind System form will be tunnel/ipsec/connection/
{line module}/left/subnet.
This form displays the private subnet behind the system.
Type
Synopsis: string - one of the following keywords { behind-system, none }
Default: none
