36. Traffic Control
ROX™ v2.2 User Guide 395 RuggedBackbone™ RX5000
The outgoing bandwidth for this interface. Specify only the number
here. The unit (kbps, mbps) is specified in Out-unit.
Unit for egress speed
Synopsis: string - one of the following keywords { bps, mbps, mbit, kbps, kbit }
Specifies the unit for the outgoing bandwidth
Description
Synopsis: string
A description for this configuration item
Incoming traffic is prioritized based on the matching ToS value in the IP header if nothing
else is configured under a band or when IP traffic does not match with the rules specified
in a band.
Speed units:
• bps = bytes per second
• mbps/kbps = megabyte/kilobyte per second
• mbits/kbits = megabits/kilobits per second
The Egress Speed and Unit for egress speed must be configured before committing a
configuration.
36.2.1.1.2. Priorities
Priorities configure traffic priorities for basic traffic shaping.
Figure 36.6. Basic Traffic Control Priorities table
To display this table, navigate to qos/traffic-control/basic-configuration/tcpriorities.
Figure 36.7. Priorities form
