5. IP Network Interfaces
ROX™ v2.2 User Guide 78 RuggedBackbone™ RX5000
The length of time in seconds during which addresses generated from the prefix remain preferred.
The default value is 604800.
Off Link
Indicates that advertisement makes no statement about on-link or off-link properties of the prefix.
No Autoconfig
Indicates to hosts on the local link that the specified prefix cannot be used for IPv6 autoconfiguration.
Set Router Address Flag
Indicates to hosts on the local link that the specified prefix contains a complete IP address by setting
the R flag.
This screen is accessible after adding an IPv6 Prefix under the Neighbor Discovery. To display the
forms, navigate to ip/{interface}/ipv6/nd/prefix.
5.3. Adding Interfaces to Switched Ports
For switched ports, you create routable interfaces by configuring VLANs. VLANs are created either
implicitly or explicitly. There are four locations in the web user interface where VLAN interfaces are
created implicitly, and one location where they are created explicitly:
Explicit/Implicit Location in the Web User Interface
Implicit interface/switch/{port}
Implicit interface/trunks
Implicit switch/mcast-filtering/static-mcast-table
Implicit switch/mac-table/static-mac-table
Explicit switch/vlans/static-vlan
Table 5.2. Locations For Creating VLAN Interfaces
The procedure below is an example of how to create explicit VLAN interfaces.
