7. DST Start Date and DST End Date: This option is provided for locations that
do not follow any of the pre-configured DST rules. Click anywhere in either
field to open a calendar, allowing you to enter any custom day & time rule.
8. Offset: In seconds. Use this field to manually define your local clock’s DST
offset e.g., 3600 seconds for a one hour offset.
9. DST Reference: When configuring a Local Clock that is synchronized to an
input reference (e.g., IRIG input), VersaSync needs to know the timescale of
the input time (Local Timescale, or UTC Timescale), in order to provide
proper internal conversion from one Timescale to another.
Select Local or UTC, depending on the Timescale of the Input reference this
Local Clock is being used with.
Additional Local Clocks may need to be created if multiple input Timescales
are being submitted.
10. Click Submit. Your local clock will appear in the Local Clocks panel.
3.2.4.2 DST Examples
The following two examples illustrate the configuration of Daylight Savings Time
(DST) for a Local Clock:
E x a m p l e 1 :
To create a Local Clock to UTC+1 with no DST rule:
1. Navigate to MANAGEMENT > Time Management: Local Clocks > (+): Local
Clock.
2. In the Local Clock Name field, assign a meaningful name to the new Local Clock.
3. From the UTC Offset pull down menu, select “UTC +01:00”.
4. Confirm that the Use DST Rules checkbox is not selected.
5. Review the changes made and click the Submit button.
The unit will display the status of the change.
E x a m p l e 2 :
To create a Local Clock for a VersaSync installed in the Eastern Time Zone of the US,
and desiring the Local Clock to automatically adjust for DST (using the post 2006 DST
rules for the US).
1. In the MANAGEMENT > Time Management: Local Clocks > (+): Local
Clock window:
170
CHAPTER 3 • VersaSync User Manual Rev. 12
