INPUTSIGNAL
Total
available
DCLS
RS-
232
RS-
485
ETH
Connector
No.
(see Fig.
above)
TTL 10V
GNSS (GPS) antenna con-
nection
(1) SMA 1
Network Interface
(10/100/1000bT):
NTP (Stratum 2), PTP
(2) 1 5
All Multi I/O interfaces (connector no. 4) are software-configurable, see "Assign-
ing I/O Pins" on page44.
1.4.2 Output Timing Interfaces
Table 1-4: VersaSync
outputs (default setup)
OUTPUTSIGNAL
Total
available
DCLS
RS- 232 RS-485 ETH
Connector No.
(see Fig. above)
TTL 10V
10 MHz (4) SMA 2
1PPS (2) 1 1 4
ASCII/HaveQuick (1) 1 4
ASCII/NMEA (1) 1 4
NTP server,
PTP v2 master
(1) 1 5
All Multi I/O interfaces (connector no. 4) are software-configurable, see "Assign-
ing I/O Pins" on page44.
10 MHz outputs can be disabled. See "The 10MHz Outputs" on page68 for more
information.
For additional information on configuring pinouts, see "Connectors and their Pin-
outs" on page10 and "Configure I/O Settings" on page48.
1.4.3 Other Interfaces
USB serial equivalent: CLI interface (Connector 4)
8
CHAPTER 1 • VersaSync User Manual Rev. 12
1.4 Interfaces Overview
