Default IPv4 Port: Unless you specify a specific Port to be used as
Default Port, the factory default port eth0 will be used as the gate-
way (default gateway).
Default IPv6 Port: Unless you specify a specific Port to be used as
Default Port, the factory default port eth0 will be used as the gate-
way (default gateway).
The General Settings window also displays the IPv4 Address and default
IPv4 Gateway.
2.8.2 Network Ports
Ports act as communication endpoints in a network. The hardware configuration
of your unit will determine which ports (e.g., Eth0, Eth1, ...) are available for use.
To enable & configure, or view a network port:
1. Navigate to MANAGEMENT > NETWORK: Network Setup.
2. The Ports panel on the right side of the screen lists the available Ethernet
ports, and their connection STATUS:
Green: CONNECTED (showing the connection speed)
Yellow: CABLE UNPLUGGED (the port is enabled but there is no
cable attached)
Red: DISABLED.
Locate the port you want to configure (eth0 or eth1) and click the
GEAR button to enable & configure the port, or the INFO button to
2.8 Configuring Network Settings
CHAPTER 2 • VersaSync User Manual Rev. 12
73
