4.3.2.2 GPS Tab: Events
Too Few GPS Sat, Minor Alarm
Too Few GPS Sat, Minor, Cleared
Too Few GPS Sat, Major Alarm
Too Few GPS Sat, Major, Cleared
GPS Antenna Problem
GPS Antenna OK
GPS Receiver Fault
GPS Receiver Fault Cleared
Under the GPSEvents tab, you can also configure Minor and Major
AlarmThresholds for GNSS fault events; see "Configuring GPS Notification
Alarm Thresholds" below.
4.3.2.3 System Tab: Events
Minor Alarm Active
Minor Alarm Inactive
Major Alarm Active
Major Alarm Inactive
Unit Reboot
Timing System Software Error
Timing System Hardware Error
High Temperature, Minor Alarm
High Temperature, Minor, Cleared
High Temperature, Major Alarm
High Temperature, Major, Cleared
4.3.3 Configuring GPS Notification Alarm Thresholds
VersaSync allows you to configure Minor and Major alarm thresholds for the
GNSS receiver. This is done by setting the minimum number of satellites the
receiver can track for a set time before an alarm is triggered. If both conditions
are met, i.e. the reception quality falls below the set number of satellites for the
set amount of time, an alarm is triggered.
