Signal Category
Measured
Accuracy
IRIG NASA 800 ns
IRIG E 1.5 μs
5.5 IRIG AM Option Card
These instructions apply to the VersaSync model 1228- 2xx4 AM- IRIG Option
Card. This card supports IRIG AM formats A, B, G, E, and NASA- 36; it also
includes up to 2 IRIG AM inputs or 4 IRIG AM outputs. Your VersaSync IRIG AM
Option Card comes pre- installed at the factory, and only requires basic con-
figuration of your unit before use.
5.5.1 Pinout for IRIGAM
There are four dedicated channels for the IRIG AM Option Card: 3 outputs and 1
input. To use these channels for the purpose of IRIG AM, you will need to set the
pinout on the multi I/O connector using the Web UI. There are four configurable
IRIG AM channels: pins 11 & 12, 13 & 14, 15 & 16, and 17 & 18 (see the chart on the fol-
lowing page for specifics on all pinout configuration options).
Pins 11 & 12 – IRIG AM Output or Input
Pins 13 & 14 – IRIG AM Output or Input
Pins 15 & 16 – IRIG AM Output
Pins 17 & 18 – IRIG AM Output
To update the pin layout and configure the IRIG AM channels:
After signing in to the unit, navigate to MANAGEMENT > NETWORK > Pin
Layout. In the Layout panel, select the plus sign in the upper right corner.
Choose IRIG-AM for the Type Filter, under Signal select either IRIG_OUT | IRIG-
AM or IRIG_IN | IRIG-AM, and select the pin set numbers for the pin pair you wish
to configure. Click Submit.
The Layout panel should display your new settings.
