HH Hours (00-23)
: Colon separator
MM Minutes (00-59)
SS Seconds (00-60)
The leading edge of the first character (CR) marks the on-time point of the data
stream.
The time synchronization status character (I) is defined as described below:
? When the receiver is unable to track any satellites and the time synchronization lamp is
red.
* When the receiver time is derived from the battery backed clock or set manually through
the Setup Port Interface.
E x a m p l e :
FRI 20APR01 12:45:36
The example data stream provides the following information:
Sync
Status
The clock is not time synchronized to GNSS. Time is derived from the battery
backed clock or set manually
Date Friday, April 23, 2015
Time 12:45:36
5.3.7 Spectracom Format 1S
Format 1S (Space) is very similar to Format 1, with the exception of a space being
the first character of Days 1 through 9 of each month (instead of the leading “0”
which is present in Format 1).
Most external systems utilizing Data Format 1 will look for a single digit day of the
month for day 1 through day 9, with a space in front of each digit (^1, ^2, ^3 … 10,
11…) whereas other systems need to see a two digit day of the month for all days 1
through 9 with a leading 0 instead of a space (01, 02, 03… 10, 11…).
If your device requires the single digit day of the month for days 1 through 9
(i.e. 1, 2, etc.), select Format 1S.
VersaSync User Manual 349
