The available options are:
I. Output Always Enabled—The output is present, even if VersaSync is not
synchronized to its references (VersaSync is free running).
II. Output Enabled in Holdover—The output is present unless VersaSync is not
synchronized to its references (VersaSync is in Holdover mode).
III. Output Disabled in Holdover—The 1PPS output is present unless the Ver-
saSync references are considered not qualified and invalid (the output is
NOT present while VersaSync is in Holdover mode.)
IV. Output Always Disabled—The output is never present, even if VersaSync
references are present and valid.
Table 2-4:
Signature control output-presence states
Ref.
Out-of-sync,
no holdover
In holdover
In-sync with
external reference
I.
II.
III.
IV.
Configuring Signature Control for an Output
To review or configure the Signature Control setting for any output:
1. Navigate to INTERFACES > OUTPUTS and click the output you want to con-
figure.
2. In the Outputs panel, click the GEAR button for the desired output. Ehe
Edit window will open with the current Signature Control setting, and a
drop-down list to change it.
2.8 Configuring Network Settings
Before configuring the network settings, you need to setup access to VersaSync
web user interface ("Web UI"). This can be done by assigning a static IP address,
