Table 1-8:
Connector Part Numbers
Ref Description
VersaSync Connector Mating (Cable) Connector
Orolia Part
No.
ODU Part No.
Orolia Part
No.
ODU Part No.
POWER Power connector,
5pin
J240R-
0051-002Q
GK1YBR-
P05UJ00-000L
P240R-
0051-002Q
S11YBR-
P05XJG0-
0000
I/O I/O connector, 26
pin
J240R-
0261-002F
GK2YAR-
P26UC00-
000L
P240R-
0261-002F
S12YAR-
P26XCD0-
0000
ETH Ethernet con-
nector, 16 pin
J240R-
0161-002F
GK1YCR-
P16UC00-000L
P240R-
0161-002F
S11YCR-
P16XCD0-
0000
SAASM,
FILL/Z
Optional I/O con-
nector, 8 pin
J240R-
0081-012F
GK1YDR-
P08UF00-
000L
P240R-
0081-002F
S11YDR-
P08XFG0-
0000
1.5.5.1 ODU
®
ordering contact information (USA):
ODU-USA Inc.
4010 Adolfo Road
Camarillo, CA 93012
United States of America
Phone: +1 (805) 484 0540
Fax: +1 (805) 484 7458
Email: sales@odu-usa.com
Note: Building the mating cables requires special tools. Contact
ODU for cable assemblies. Be advised that typical lead times are 12
to 16 weeks.
ETHERNET connector wiring:
1 through 8: A Ethernet Connect, 4 pairs, 1000bT (in the software, eth0)
9 through 16: B Ethernet Connect, 4 pairs, 1000bT (in the software, eth1)
POWER connector pinout
1: V
Main
, 10 to 32 V
DC
2: -not used-
3: V
Standby
, 10 to 32 V
DC
(Standby Power)
14
CHAPTER 1 • VersaSync User Manual Rev. 12
1.5 Connectors and their Pinouts
