2.1.3 SAFETY: Other Tips
Keep these instructions at hand, near the place of use.
Keep your workplace tidy.
Apply technical common sense: If you suspect that it is unsafe to use the
product, do the following:
Disconnect the supply voltage from the unit.
Clearly mark the equipment to prevent its further operation.
2.2 Installation Overview
The steps that need to be performed prior to putting VersaSync into service
include:
Installation: Hardware setup, mechanical installation, physical connections.
Setup: Establish basic access to the unit, so as to allow the use of the web
user interface ("WebUI").
Configuration: Access the Web UI, configure the network, input and output
references, protocols (e.g., NTP), other settings.
Not all of the setup steps described in this manual may apply to you. Your unit
installation relative to other connected devices, the cable selection and man-
ufacturing, your chosen power source, your project-specific infrastructure, and
your planned access to your unit (either WebUI or CLI), could all affect your
setup needs.
2.2.1 Hardware Connections
During the procedure described below, you will connect the Power cable, the
Multi I/O cable, and the Ethernet cable.
The step-by-step instructions below outline the VersaSync installation and con-
figuration process:
1. Install VersaSync in the designated vehicle:
The mounting plate should be in direct contact with the unit base
plate, so as to conduct heat.
For more detail on mounting your unit, see "Mounting" on page32.
30
CHAPTER 2 • VersaSync User Manual Rev. 12
