2. Connect the power supply. The unit will power up, and the ON/OFF status
LED will pulsate.
Requirement Action Evaluation kit cable
Power up Connect 12 V
DC
to the
power connector.
Attach a cable and apply 12 V
DC
to the plug
labeled "Main" (CA08R-CRPB-0002)
Caution: If your unit does not power up, and this is your first
installation using your cables, check the polarity of the wires
and confirm that the unit will power up normally before pro-
ceeding with these steps or making any other connections.
3. Install the GNSS antenna(s). Follow your antenna manufacturer's instruc-
tions. :
For additional information on GNSS antenna installation considerations,
including cabling, an Orolia tech note is available here.
4. Wire the antenna cables and interface cables. Most customers will require
the Multi I/O and Ethernet cables for these connections, as well as a PC..
Requirement Action Evaluation kit cable
USB con-
nection
Connect USB to the Multi
I/O connector.
Connect the USB connector to a PC with a
terminal emulator program (CA08R-
CRUB-0002)
Network con-
nection
Connect at least one of
the two Ethernet con-
nectors to a network.
Connect the RJ45 jack labeled ETH0 or
ETH1 to a network hub/switch or directly
to a PC (CA08R-CRET-0002)
USB: Connect the Multi I/O connector to the VersaSync unit. If you
are using the Evaluation Kit, connect the Multi I/O USB output to a
PC. Install a terminal emulator program on the PC (e.g., TeraTerm
®
or
PuTTY
®
).
Ethernet: Connect the Ethernet cable to one of the ETH ports of the
unit. If you are using the Evaluation Kit, connect at least one of the
two I/O cable Ethernet ports (ETH0 or ETH1) to a network
switch/hub, or to the PC mentioned above (using a standard Ethernet
patch cable, or a crossover cable).
For pinout tables, see "Connectors and their Pinouts" on page10 and "Con-
figuring Inputs/Outputs" on page43.
