1.7.2 GNSS Receiver
VersaSync has an integrated state-of-the-art GNSS receiver, suitable for con-
current dual-constellation reception.
Compatible signals:
GPS L1 C/A (center frequency 1575.42 MHz)
GLONASS L10F (center frequency 1602.0 MHz)
Galileo E1 B/C (center frequency 1575.42 MHz)
QZSS L1-SAIF (center frequency 1575.42 MHz)
BeiDou B1 (center frequency 1561.098 MHz)
Satellites tracked: Up to 72 simultaneously
Update rate: up to 2Hz (concurrent)
Acquisition time: Typically <27seconds from cold start
Antenna requirements: Active antenna module, +5V, powered by VersaSync,
16dB gain minimum
Antenna connector: SMA
1.7.3 Output References
1.7.3.1 10 MHz Output
Signal: 10 MHz sine wave
Signal Level: +10 dBm ±2dB into 50 Ω
Harmonics: ˗40 dBc minimum
Spurious: ˗60 dBc minimum OCXO
Connector: SMA female
Signature Control: This configurable feature removes the output signal
whenever a major alarm condition or loss of time synchronization condition
is present. The output will be restored once the fault condition is corrected.
Table 1-9:
10 MHz output — oscillator types and accuracies
Oscillator Type Accuracy
OCXO 2x10
-12
typical 24-hour average locked to GPS
1x10
-9
per day typical aging unlocked
