RF200 system planning
4.3 Installation guidelines
SIMATIC RF200
System Manual, 07/2015, J31069-D0227-U001-A9-7618
61
Transponder
RF250R with ANT 8
antenna without met-
al
antenna flush-
mounted in metal
MDS D127
without metal
100
85
flush-mounted in metal;
distance all round 0 mm
70 60
MDS D421
without metal
100
85
flush-mounted in metal;
distance all round 0 mm
75 70
MDS D521
without metal
100
85
flush-mounted in metal;
distance all round 0 mm
75 70
Table 4- 21 Reduction of field data due to metal, range as %: Transponder and RF250R with ANT 12
Transponder
RF250R with ANT 12
antenna without met-
al
antenna flush-
mounted in metal
(all round 7 mm)
MDS D117
without metal
100
85
flush-mounted in metal;
distance all round 0 mm
50 40
MDS D127
without metal
100
85
flush-mounted in metal;
distance all round 0 mm
65 50
MDS D160
1)
without metal
100
90
on metal, distance 10 mm
90
85
MDS D421
without metal
100
90
flush-mounted in metal;
distance all round 0 mm
65 45
MDS D422
without metal
100
90
flush-mounted in metal;
distance all round 0 mm
90 75
MDS D425
without metal
100
90
on metal, distance 0 mm
115
2)
100
MDS D428
without metal 100 85
on metal, distance 0 mm
110
2)
95
MDS D460
1)
without metal
100
95
on metal, distance 10 mm
90
80
flush-mounted in metal;
distance all round 0 mm
85 75
MDS D521
without metal
100
90
flush-mounted in metal;
distance all round 0 mm
65 45
