Siemens SIMATIC Ident System Manual

RF200 system planning
4.3 Installation guidelines
SIMATIC RF200
62 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Transponder
RF250R with ANT 12
antenna without met-
al
antenna flush-
mounted in metal
(all round 7 mm)
MDS D522
without metal
100
90
flush-mounted in metal;
distance all round 0 mm
90 75
MDS D528
without metal
100
85
on metal, distance 0 mm
110
2)
95
1)
Mounting the transponder on or in metal is only possible with the appropriate spacer or if there is
adequate clearance to the metal.
2)
Values of > 100 % related to non metal surroundings can occur if transponders were developed
specifically for mounting in/on metallic surroundings.
Table 4- 22 Reduction of field data due to metal, range as %: Transponder and RF250R with ANT 18
Transponder
RF250R with ANT 18
antenna without met-
al
antenna flush-
mounted in metal
(all round 10 mm)
MDS D124
1)
without metal
100
80
on metal, distance 15 mm
100
80
flush-mounted in metal;
distance all round 25 mm
95 70
MDS D160
1)
without metal
100
90
on metal, distance 10 mm
100
90
MDS D324
1)
without metal
100
80
on metal, distance 15 mm
100
80
flush-mounted in metal;
distance all round 25 mm
95 75
MDS D421
without metal
100
85
flush-mounted in metal;
distance all round 0 mm
65 50
MDS D422
without metal
100
100
flush-mounted in metal;
distance all round 0 mm
90 90
MDS D423
without metal
100
85
on metal, distance 0 mm
120
2)
110
2)
flush-mounted in metal;
distance all round 10 mm
90 75
MDS D424
1)
without metal
100
75
on metal, distance 15 mm
95
75
flush-mounted in metal;
distance all round 25 mm
95 75
