Steris Vision 1321 - Alarm #11: Water Recycling Malfunction; Alarm #12: Water Recirculation Temperature Too High

7 — Routine Maintenance
152
920515770_J
Vision® 1300 Series
Operator Manual
.
9. Reinstall pivot, washer, O-ring and end caps on spray arm assembly using previously removed pins.
1 O-Ring
2 Washer
2 Pivot
.
10. Once cleaning procedure is completed, reinstall rotary spray arm assembly to Instrument Washing Manifolded
Rack using previously removed pin.
