5 — Operating Instructions
43
Operator Manual
Vision® 1300 Series
920515770_J
• 40 to 72 small trays of 9 to 13 x 5 to 10”
(229 to 330 x 127 to 254 mm);
• 32 bedpans, or;
• 96 theatre shoes.
When loading Vision CW Utensil Rack, ensure:
• to place basins, trays and theatre shoes with opening facing down in rack;
• to place bedpans, position wire supports vertically and place bedpans with opening facing down in rack;
• no items stick out of rack;
• to place larger and heavier items on the bottom shelf.
.
5.11 Loading Vision CW Instrument Washing Manifolded Rack (Option)
WARNING
PERSONAL INJURY AND/OR EQUIPMENT DAMAGE HAZARD
Always use a hold-down screen to secure small or light items. While loading instrument racks, do not
place miscellaneous articles on the sides of instrument trays. Incorrect rack loading/overloading could
lead to injury and/or damage to the equipment or instruments.
