4.25 Service Mode
The Service mode allows a qualified service technician to access the Service mode menu to configure the
washer/disinfector and to perform preventive maintenance, testing and troubleshooting. The Service mode is not
accessible to the operator or the supervisor.
Only a qualified service technician can access the Service mode. A predefined password is required to access Service
mode. Refer to Maintenance Manual of corresponding equipment for details about Service mode.
.
4.26 Touch Pads - Door Control
OPEN/CLOSE DOOR: Press Open/Close door to open or close wash chamber door. Touch pad on load side
touch screen operates load side door. Touch pad on unload side touch screen operates unload door.
NOTE: While trying to open a door, note the following:
1. If unload door is open, operator needs to close unload door to be able to open load door.
2. If load door is open, operator needs to close load door and successfully process a complete cycle to be able to
open unload door.
4.27 Touch Pads - Cycle Processing
Refer to , for details on each validated cycle.
SLIDER: For forward and back navigation. Slider is displayed next to Left and Right arrow on touch screen. Slider
allows to scroll across a screen to view all menus and/or possible selections available.
CART STD: Press Cart STD on touch screen to select the validated CART STANDARD cycle. Used to process
surgical case carts 44-inches high or more.
