Steris Vision 1321 - Bar Code Reader (Accessory); Control System - Touch Screens

4 — Component Identification
25
Operator Manual
Vision® 1300 Series
920515770_J
1. Printer
2. Unload Side Control Panel
.
4.18 Bar Code Reader (Accessory)
The bar code reader (accessory) is located next to washer/disinfector load door, under Emergency Stop pushbutton.
Bar code reader is used to automatically identify and initiate the appropriate cycle by scanning a bar code tag attached
on utensils, container or instruments rack.
1. Bar Code Reader (Accessory)
2. Load Side Control Panel
.
4.19 Control System - Touch Screens
Washer/disinfector is equipped with two touch screens: one on the load side and one on the unload side. Identical
information is simultaneously displayed on both sides.
