STONEX R2 User Manual

STONEX R2
72
OPERATIONAL STEPS
OPERATION
DISPLAY
① Input the first backsight PtID and
reflector height, and press [ENT]
to enter into backsight
measurement function.
Input PtID
+
[ENT]
【Known Pt】
Input BsPt!
BsPt ： BS1
R. HT： 1.860 m
LIST ENH
② With Face Ⅰ, collimate on
backsight point BS1, press [F1] (All)
or [F2] (DIST) + [F3] (RECORD) to
start orientation with coordinate
measurement.
Press [PAGE] to display Page 2 of
backsight measurement.
[F1]
or
[F2]
+
[F3]
【Known Pt 】 1/2 1/ ▼
Bs Pt： BS1
R. HT： 1.860 m
HZ： 0°00′00″
V ： 90°00′00″
： ﹉ .﹉ m Ⅰ
： ﹉ .﹉ m
All DIST RECORD EDM
【Known Pt 】 2/2 2/ ▼
Bs Pt： BS1
R. HT： 1.860 m
HZ： 0°00′00″
△AZ ： --°--′--″
： ----.---- m Ⅰ
All DIST RECORD EDM
③ After measurement, the screen
displays “Want More Measurement?”.
Press [F4] to confirm it.
[F4]
Want More Measurement?
CANCEL OK
