5C-4 PARKING AND REAR BRAKE
Parking Brake Cable Component Location
1. Parking brake lever assembly 4. Parking cable bracket 7. Parking brake cable bolt
2. Equalizer 5. Parking brake cable:
Apply water tight sealant 99000-31090 to plate and cable contact.
8. Parking brake lever bolt
3. Adjusting nut 6. Grommet Tightening torque
