7B1-120 AUTOMATIC TRANSAXLE (M13 ENGINE)
Unit Disassembly
Components
CAUTION:
• Thoroughly clean transaxle exterior before overhauling
it.
• Keep working table, tools and hands clean while over-
hauling.
• Use special care to handle aluminum parts so as not to
damage them.
• Do not expose removed parts to dust. Keep them
always clean.
NOTE:
Oil pump assembly, direct clutch assembly, forward and
reverse clutch assembly, 2nd brake piston assembly, O/D
and 2nd coast brake piston and return spring, differential
assembly, countershaft assembly and valve body assem-
bly are not shown in figure below.
For the detail of these components, refer to “Disassem-
bly/Assembly of Subassembly” in this section.
To Next Page
