4B-2 PROPELLER SHAFTS
On-Vehicle Service
ON-VEHICLE INSPECTION
• Check propeller shaft connecting bolts for looseness. If
looseness is found, tighten to specified torque.
• Check propeller shaft joints for wear, rattle and damage. If
any defect is found, replace.
• Check propeller shaft center support for biting of foreign mat-
ter, crack, abnormal noise and damage. If any defect is
found, replace.
[A]: Forward. 4. Propeller shaft No.2 bolt
: Apply thread lock 99000-32110 to thread.
8. Center support bolt
1. Propeller shaft No.1 with center support 5. Dynamic damper Tightening torque
2. Viscous coupling with center support 6. Propeller shaft bolt
3. Propeller shaft No.2 7. Viscous coupling nut
